Face Mills • Victory™ M1200 Mini Series
Victory M1200 Mini • Shell Mills
• Twelve cutting edges.
• First choice for low depth-of-cut face milling.
• Maximum number of teeth per diameter.
Shell Mills
order number
catalogue number
coolant
D1 D1 max D D6 L L2 Ap1 max Z max RPM supply
kg
3957995
M1200D040Z04HN07 40
48,7 22 38 40 40
3,5
4 15800
Yes 0,26
3957996
M1200D040Z05HN07 40
48,7 22 38 40 40
3,5
5 15800
Yes 0,26
3957997
M1200D050Z04HN07 50
58,7 22 38 40 40
3,5
4 12700
Yes 0,35
3957998
M1200D050Z05HN07 50
58,7 22 38 40 40
3,5
5 12700
Yes 0,36
M1200D050Z06HN07 50
58,7 22 38 40 40
3,5
6 12700
Yes 0,35
3958000
M1200D063Z04HN07 63
71,7 22 50 40 40
3,5
4 10100
Yes 0,58
3958001
M1200D063Z06HN07 63
71,7 22 50 40 40
3,5
6 10100
Yes 0,65
3958002
M1200D063Z08HN07 63
71,7 22 50 40 40
3,5
8 10100
Yes 0,62
3958003
M1200D080Z05HN07 80
88,7 27 60 50 50
3,5
5 7900
Yes 1,11
3958004
M1200D080Z08HN07 80
88,7 27 60 50 50
3,5
8 7900
Yes 1,24
3958005
M1200D080Z10HN07 80
88,7 27 60 50 50
3,5
10 7900
Yes 1,17
3958006
M1200D100Z06HN07 100
108,7
32 80 50 50
3,5
6 6300
Yes 1,71
3958007
M1200D100Z09HN07 100
108,7
32 80 50 50
3,5
9 6300
Yes 1,82
3958008
M1200D100Z12HN07 100
108,7
32 80 50 50
3,5
12 6300
Yes 1,82
4138470
M1200D125Z08HN07 125
133,7
40 90 63 —
3,5
8 5050
Yes 2,84
4138471
M1200D125Z12HN07 125
133,7
40 90 63 —
3,5
12 5050
Yes 2,96
4138472
M1200D125Z16HN07 125
133,7
40 90 63 —
3,5
16 5050
Yes 3,02
Spare Parts
insert
Torx
D1 screw Nm driver
socket-head
cap screw
mounting screw
with coolant grooves
coolant
screw assembly
40 12146034500 3,5 12148082400
—
12146109200
—
50 12146034500 3,5 12148082400
12146120500
—
—
63 12146034500 3,5 12148082400
12146120500
—
—
80 12146034500 3,5 12148082400
12748701000
—
—
100 12146034500 3,5 12148082400
—
— 12146109400
125 12146034500 3,5 12148082400
—
—
—
NOTE: Mounting screw with coolant groove, coolant screw assembly, coolant lock screw, and coolant cap must be ordered separately.
coolant
lock screw
coolant
cap
——
——
——
——
——
12146107000 12146111000
