Application Examples
для размещения заказа - zakaz@widiahanita.ru
Victory™ Shoulder Mills • VSM11™ Series
Application Data
ramp angle
ramping
helical
interpolation
shoulder cut
DH min = Minimum blind hole diameter with helical interpolation
DH1 max = Maximum blind hole diameter with flat bottom
DH/DH1
order number
5417011
5417013
5417015
5417017
5417019
5416454
5416455
5416457
5416458
5416459
5416480
5416481
5416482
5416483
5416632
5416633
5416634
5416635
5416637
5416636
5416638
5416639
5416700
5416701
5416703
5416702
5416704
5416705
5416706
5416707
5416316
5416317
5416318
5416319
5416340
5416341
5416342
5416345
5416347
catalogue number
VSM11D016Z02M08XD11
VSM11D020Z03M10XD11
VSM11D025Z04M12XD11
VSM11D032Z04M16XD11
VSM11D040Z06M16XD11
VSM11D012Z01B16XD11
VSM11D016Z02B16XD11
VSM11D020Z02B20XD11
VSM11D020Z03B20XD11
VSM11D025Z03B25XD11
VSM11D025Z04B25XD11
VSM11D030Z04B25XD11
VSM11D032Z04B32XD11
VSM11D032Z05B32XD11
VSM11D012Z01A16XD11L100
VSM11D016Z02A16XD11L100
VSM11D020Z02A20XD11L110
VSM11D020Z03A20XD11L110
VSM11D025Z04A25XD11L120
VSM11D025Z03A25XD11L120
VSM11D032Z03A32XD11L130
VSM11D032Z05A32XD11L130
VSM11D016Z02A16XD11L170
VSM11D018Z02A16XD11L170
VSM11D020Z03A20XD11L170
VSM11D020Z02A20XD11L170
VSM11D022Z03A20XD11L170
VSM11D025Z03A25XD11L210
VSM11D025Z04A25XD11L210
VSM11D032Z03A32XD11L250
VSM11D040Z04S016XD11
VSM11D040Z06S016XD11
VSM11D050Z05S022XD11
VSM11D050Z08S022XD11
VSM11D063Z06S022XD11
VSM11D063Z09S022XD11
VSM11D080Z08S027XD11
VSM11D100Z09S032XD11
VSM11D125Z011S040XD11
number
of inserts
2
3
4
4
6
1
2
2
3
3
4
4
4
5
1
2
2
3
4
3
3
5
2
2
3
2
3
3
4
3
4
6
5
8
6
9
8
9
11
max
RPM
41400
35100
30200
25800
22600
53100
41400
35100
35100
30200
30200
26900
25800
25800
53100
41400
35100
35100
30200
30200
25800
25800
41400
37900
35100
35100
32900
30200
30200
25800
22600
22600
19900
19900
17500
17500
15300
13600
12100
NOTE: For DH1 max, subtract the insert corner radius from the max hole diameter.
max ramp angle to
steel body interference
10.00°
7.80°
5.30°
3.60°
2.60°
3.70°
10.00°
7.80°
7.80°
5.30°
5.30°
3.20°
3.60°
3.60°
4.00°
10.00°
8.00°
8.00°
5.00°
5.00°
4.00°
4.00°
10.00°
10.00°
8.00°
8.00°
7.00°
5.00°
5.00°
4.00°
3.00°
3.00°
2.00°
2.00°
2.00°
2.00°
1.00°
0.90°
0.70°
max at-bottom
hole diameter
(DH1 max)
32,00
40,00
50,00
64,00
80,00
24,00
32,00
40,00
40,00
50,00
50,00
60,00
64,00
64,00
24,00
32,00
40,00
40,00
50,00
50,00
64,00
64,00
32,00
36,00
40,00
40,00
44,00
50,00
50,00
64,00
80,00
80,00
100,00
100,00
126,00
126,00
160,00
200,00
250,00
zakaz@widiahanita.ru
www.widiahanita.ru
min hole
diameter
(DH min)
19,00
27,00
37,00
51,00
67,00
11,00
19,00
27,00
27,00
37,00
37,00
47,00
51,00
51,00
11,00
19,00
27,00
27,00
37,00
37,00
51,00
51,00
19,00
23,00
27,00
27,00
31,00
37,00
37,00
51,00
67,00
67,00
87,00
87,00
113,00
113,00
147,00
187,00
237,00
J15
