WIDIA™ Victory™ Shoulder Mill 17™ •
VSM17™
VSM17
WIDIA Victory Shoulder Mill 17 is a high-performance, versatile, robust, 90° square shoulder milling platform. VSM17 is
designed for versatility, low horsepower consumption, and easy cutting action. Cutters can be used for shoulder milling,
proling, face milling, slotting, ramping, helical interpolation, and circular interpolation milling applications. Inserts are
specially designed with innovative geometries and features like variable rake angles, negative T-land, small hone, and the
latest Victory grades enhancing tool performance and versatility.
Take advantage of the high-performance, advanced carbide substrates, coatings, and surface treatment technologies of
the available 7 Victory grades, 4 geometries, and a broad-range cutter body product portfolio. This platform works with
multiple material types and applications.
• Up to 16,33mm (.65") depth-of-cut capabilities.
• State-of-the-art step down capability.
• Screw-on, end mill, and shell mill cutters with effective
internal coolant supply.
Features
• Insert geometries and grades for all workpiece materials.
• Insert corner radius from 0,4–4mm (.015–.157").
• Max axial depth of cut 16,3mm (0.65").
Benets
• Achieve true 90° wall nish.
• High performance and longer tool life.
• Latest WIDIA Victory milling grades for
all workpiece materials.
• High positive geometry, soft cutting action,
reduced cycle times, and low horsepower
consumption.
• Stability and reliability.
Multiple corner
nose radii available.
Optimised cutting edge
and positive rake face
for reduced cutting
forces and softer
cutting action.
Innovative cutting
geometry provides
superior wall and
surface nish.
