Copy Mills • M170™ Series
Screw-On End Mills • RD1003..
для размещения заказа - zakaz@widiahanita.ru
• Premium nickel-coated bodies.
• Designed for maximum performance.
• Ideally suited for die and mould manufacturing.
Screw-On End Mills
order number
catalogue number
D1 max D1 D
max
ramp
coolant
DPM G3X L2 WF Ap1 max Z angle max RPM supply
kg
3934647 M170D020Z02M10RD10 20 10 18 10,5 M10 30 15 5,0 2 20.0° 15900
Yes 0,06
3934648 M170D025Z02M12RD10 25 15 21 12,5 M12 35 19
5,0
2 8.0°
12800
Yes 0,10
3934649 M170D025Z03M12RD10 25 15 21 12,5 M12 35 19
5,0
3 8.0°
12800
Yes 0,10
3934650 M170D030Z04M16RD10 30 20 29 17,0 M16 43 22 5,0 4 10.0° 10600
Yes 0,24
3934651 M170D035Z05M16RD10 35 25 29 17,0 M16 45 22 5,0 5 8.5° 9100
Yes 0,23
3934652 M170D042Z06M16RD10 42 32 29 17,0 M16 45 22 5,0 6 6.0° 7800
Yes 0,28
Spar Parts
insert
screw
193.342
NOTE: All spare parts except the insert screws must be ordered separately.
Nm
3,5
Torx
driver
12148082400
M52
