• Rough, semi-finishing, and finishing with one system.
• Through tool coolant.
• Carbide shank to improve rigidity.
Copy Mills • M270™ Series
Ball Nose Tool Bodies
Ball Nose • Carbide Cylindrical Shanks
order number
catalogue number
D1 D
L L2 Z Z U
inserts
max RPM
coolant
supply
kg
2424550
M270BD010A12L140C 10 12 140 45 1 2 M270B.10
57000
Yes 0,20
2424587
M270BD012A12L145C 12 12 145 50 1 2 M270B.12
55000
Yes 0,20
2424634
M270BD016A16L155C 16 16 155 57 1 2 M270B.16
53000
Yes 0,40
2639257
M270BD020A20L170C 20 20 170 70 1 2 M270B.20
52000
Yes 0,65
NOTE: ZU = Effective teeth.
Z = number of pocket seats.
Spare Parts
insert
D1 screw
10 12748610500
12 12748610600
16 12748610700
20 12748610800
NOTE: All spare parts except the insert screws must be ordered separately.
Nm
2,0
2,0
5,0
5,0
Torx
driver
12148788900
12148788900
12148099300
12148099300
