High-Performance Solid Carbide End Mills • VariMill™
Series 77NE • VariMill III™ ER • With Neck • Victory™ Grades
• Unequal flute spacing.
• Centre cutting.
• Ramping angle 3°.
• Optimised for difficult-to-machine
workpiece materials.
• Semi-finishing to finishing applications.
• High-speed machining capability.
• Standard items listed. Additional styles
and coatings made-to-order.
Detail X
Series 77NE • VariMill III ER • With Neck • Victory Grades
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
WS15PE
AlTiN
length of cut
length
order # catalogue # D1 D
D3
Ap1 max
L3
L R BCH
5978039 77NE10004T 10,0 10
9,40
22,00
30,00
76
— 0,50
5978040 77NE10024T 10,0 10
9,40
22,00
30,00 76 0,50 —
5978096 77NE12005T 12,0 12 11,28
26,00
36,00
83
— 0,50
5978097 77NE12025T 12,0 12 11,28
26,00
36,00 83 0,50 —
5978104 77NE16006T 16,0 16 15,04
32,00
48,00
100
— 0,50
5978105 77NE16026T 16,0 16 15,04
32,00
48,00 100 0,50 —
5978112 77NE20007T 20,0 20 18,80
38,00
60,00
115
— 0,50
5978113 77NE20027T 20,0 20 18,80
38,00
60,00 115 0,50 —
O44
