High-Performance Solid Carbide End Mills • VariMill™
Series 771E 772E • VariMill III™ ER • Victory™ Grades
• Unequal flute spacing .
• Centre cutting.
• Ramping angle 3°.
• Optimised for difficult-to-machine
workpiece materials.
• Semi-finishing to finishing applications.
• High-speed machining capability.
• Standard items listed. Additional styles
and coatings made-to-order.
Detail X
Series 771E 772E • VariMill III ER • Victory Grades
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
WSP15PE
AlTiN
order #
5978092
5978093
5978094
5978095
5978098
5978099
5978100
5978101
5978106
5978107
5978108
5978109
5978114
5978115
5978116
5978117
catalogue #
771E10004T
771E10024T
772E10004T
772E10024T
771E12005T
771E12025T
772E12005T
772E12025T
771E16006T
771E16026T
772E16006T
772E16026T
771E20007T
771E20027T
772E20007T
772E20027T
first choice
alternate choice
WPS15PE
AlTiN
length of cut
length
order # catalogue # D1 D
Ap1 mx
L
—
10,0 10
30,00
76
R BCH
— 0,50
—
10,0 10
30,00
76 0,50 —
—
10,0 10
50,00
100 — 0,50
—
10,0 10
50,00
100 0,50 —
—
12,0 12
36,00
100 — 0,50
—
12,0 12
36,00
100 0,50 —
5978102 772E12005V
12,0 12
60,00
125 — 0,50
5978103 772E12025V
12,0 12
60,00
125 0,50 —
—
16,0 16
48,00
110 — 0,50
—
16,0 16
48,00
110 0,50 —
5978110 772E16006V
16,0 16
80,00
141 — 0,50
5978111 772E16026V
16,0 16
80,00
141 0,50 —
—
20,0 20
60,00
125 — 0,50
—
20,0 20
60,00
125 0,50 —
5978118 772E20007V
20,0 20
100,00
166 — 0,50
5978119 772E20027V
20,0 20
100,00
166 0,50 —
