High-Performance Solid Carbide End Mills • Roughing
Series DQ13 • Victory™ Grades
• Centre cutting.
• Chipbreaker pitch.
• Standard items listed. Additional
styles and coatings made-to-order.
Series DQ13 • Victory Grades
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h11
+/-
D
0/-0,060
)3
0/-0,075
> 3–6
0/-0,09
> 6–10
0/-0,11
> 10–18
0/-0,13
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
altenate choice
graWdePW15PP1E5PE
AlTiN
order # catalogue #
graWdePW15PP1E5PE
AlTiN
order # catalogue #
D1
length of cut
length
D Ap1 max
L
5560534 DQ1303002T
5560536 DQ1303002W
3,0
6
7,00
54
5560535 DQ1304002T
5560537 DQ1304002W
4,0
6
8,00
57
–
5560538 DQ1305002W
5,0
6
10,00
57
–
5560539 DQ1306002W
6,0
6
10,00
57
–
5560700 DQ1307003W
7,0
8
13,00
63
–
5560701 DQ1308003W
8,0
8
16,00
63
–
5560702 DQ1310004W
10,0
10
19,00
72
–
5560703 DQ1312005W
12,0
12
22,00
83
–
5560704 DQ1314014W
14,0
14
22,00
83
–
5560705 DQ1316006W
16,0
16
32,00
92
–
5560706 DQ1318018W
18,0
18
32,00
92
–
5560707 DQ1320007W
20,0
20
38,00
104
R
0,25
0,25
0,25
0,45
0,45
0,45
0,45
0,45
0,45
0,45
0,45
0,45
