High-Performance Solid Carbide End Mills • Roughing
Series 022813 422813
• Centre cutting.
• Flat shallow pitch.
• Standard items listed. Additional
styles and coatings made-to-order.
Detail X
Series 022813 422813
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h10
+/-
D
0/-0,04
)3
0/-0,048
> 3–6
0/-0,058
> 6–10
0/-0,070
> 10–18
0/-0,084
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choie
graKde30KF30F
uncoated
order # catalogue #
graKde30KF3-0DFC-FDCF
TiAlN
order # catalogue #
D1
length of cut
length
D Ap1 max
L
2332360 022813-000060
2342043 422813-000060
6,0
6
10,00
57
2332361 022813-000080
2342045 422813-000080
8,0
8
16,00
63
2332362 022813-000100
2342047 422813-000100
10,0
10
19,00
72
2332363 022813-000120
2342049 422813-000120
12,0
12
22,00
83
2332364 022813-000160
2342051 422813-000160
16,0
16
26,00
92
2332365 022813-000200
2342053 422813-000200
20,0
20
32,00
104
2332366 022813-000250
2342055 422813-000250
25,0
25
45,00
121
BCH
0,10
0,20
0,30
0,30
0,40
0,40
0,40
