High-Performance Solid Carbide End Mills • Roughing
Series 4969
• Centre cutting.
• Flat shallow profile.
• Standard items listed. Additional
styles and coatings made-to-order.
• Roughing profile also on radii portion
of end mill.
Series 4969
graTdieATlNiA-LlNW-LW
TiAlN
order #
3881115
3881116
3881117
3881118
3881119
3881120
3881121
3881122
3881123
catalogue #
496905002LW
496906002LW
496908003LW
496910004LW
496912005LW
496914014LW
496916006LW
496918018LW
496920007LW
D1
5,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance d11
-0,020/-0,080
-0,030/-0,105
-0,040/-0,130
-0,050/-0,160
-0,065/-0,195
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
length of cut
length
D Ap1 max L
6
13,00
57
6
13,00
57
8
16,00
63
10 22,00 72
12 26,00 83
14 26,00 83
16 32,00 92
18 32,00 92
20
38,00
104
ZU
3
3
4
4
4
4
4
4
4
