High-Performance Solid Carbide End Mills • Finishing
Series 4001 JJ • JIS • Victory™ Grades
• Centre cutting.
• Standard items listed. Additional
styles and coatings made-to-order.
Series 4001 JJ • Victory Grades
graWdePW15PP1E5PE
AlTiN
order #
5559146
5559147
5559148
5559149
5559160
5559161
5559162
5559163
5559164
5559165
5559166
5559167
5559168
5559169
catalogue #
400101001T
400101501T
400102001T
400103002T
400104002T
400105002T
400106002T
400108003T
400110004T
400112005T
400114005T
400116006T
400118006T
400120007T
D1
1,0
1,5
2,0
3,0
4,0
5,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
D
4
4
4
6
6
6
6
8
10
12
14
16
18
20
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
length of cut
D3 Ap1 max
— 3,00
— 3,00
— 3,00
— 9,50
— 12,00
— 14,00
5,6 16,00
7,5 20,00
9,4 22,00
11,3 25,00
13,2 32,00
15,0 32,00
16,9 38,00
18,8 38,00
length
L3 L
3 50
3 50
3 50
10 58
12 76
14 76
40 100
40 100
35 100
50 125
57 125
60 150
60 150
60 150
O84
