High-Performance Solid Carbide End Mills • Finishing
Series D503 D513
• Centre cutting.
• Standard items listed. Additional
styles and coatings made-to-order.
Series D503 D513
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
graUdNeCUONACTOEADT-EWD-WWW
order # catalogue #
gradTeICTNiC-CNW-CW
TiCN
order # catalogue #
gradTeiATlNiA-RlNW-RW
TiAlN
order # catalogue #
length of cut
length
D1 D
Ap1 max
L
1661576 D50302002WW
1661573 D50302002CW
1661574 D50302002RW
2,0
6
3,00
50
1661580 D50303002WW
1661577 D50303002CW
1661578 D50303002RW
3,0
6
4,00
50
1661682 D51303002WW
—
1661680 D51303002RW
3,0
6
7,00
57
1661585 D50304002WW
1661582 D50304002CW
1661583 D50304002RW
4,0
6
5,00
54
1661686 D51304002WW
—
1661684 D51304002RW
4,0
6
8,00
57
1661590 D50305002WW
1661587 D50305002CW
1661588 D50305002RW
5,0
6
6,00
54
1661690 D51305002WW
—
1661688 D51305002RW
5,0
6
10,00
57
1661595 D50306002WW
1661592 D50306002CW
1661593 D50306002RW
6,0
6
7,00
54
1661694 D51306002WW
—
1661692 D51306002RW
6,0
6
10,00
57
1661605 D50308003WW
1661601 D50308003CW
1661603 D50308003RW
8,0
8
9,00
58
1661703 D51308003WW
—
1661701 D51308003RW
8,0
8
16,00
63
1661614 D50310004WW 1661611 D50310004CW 1661612 D50310004RW 10,0 10
11,00
66
1661712 D51310004WW
—
1661710 D51310004RW 10,0 10
19,00
72
1661619 D50312005WW
—
1661617 D50312005RW 12,0 12
12,00
73
1661717 D51312005WW
—
1661715 D51312005RW 12,0 12
22,00
83
—
—
1661622 D50314014RW 14,0 14
14,00
75
—
—
1661720 D51314014RW 14,0 14
22,00
83
1661629 D50316006WW
—
1661627 D50316006RW 16,0 16
16,00
82
1661727 D51316006WW
—
1661725 D51316006RW 16,0 16
26,00
92
1661732 D51318018WW
—
1661730 D51318018RW 18,0 18
26,00
92
—
—
1661636 D50320007RW 20,0 20
20,00
92
1661737 D51320007WW
—
1661735 D51320007RW 20,0 20
32,00
104
