High-Performance Solid Carbide End Mills • Finishing
Series D507 D517 • Victory™ Grades
• Centre cutting.
• Standard items listed. Additional
styles and coatings made-to-order.
Series D507 D517 • Victory Grades
graWdePW15PP1E5PE
AlTiN
order #
5559100
5559108
5559101
5559109
5559102
5559110
5559103
5559111
5559104
5559112
5559105
5559113
5559106
5559114
5559107
5559115
catalogue #
D50706002W
D51706002W
D50708003W
D51708003W
D50710004W
D51710004W
D50712005W
D51712005W
D50714014W
D51714014W
D50716006W
D51716006W
D50718018W
D51718018W
D50720007W
D51720007W
D1
6,0
6,0
8,0
8,0
10,0
10,0
12,0
12,0
14,0
14,0
16,0
16,0
18,0
18,0
20,0
20,0
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
length of cut
length
D Ap1 max L
6
10,00
54
6
13,00
57
8
12,00
58
8
19,00
63
10 14,00 66
10 22,00 72
12 16,00 73
12 26,00 83
14 18,00 75
14 26,00 83
16 22,00 82
16 32,00 92
18 24,00 84
18 32,00 92
20 26,00 92
20
38,00
104
