High-Performance Solid Carbide End Mills • Finishing
Series 422822 422826
• Non-centre cutting.
• Standard items listed. Additional
styles and coatings made-to-order.
Detail X
Series 422822 422826
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h10
+/-
D
0/-0,040
)3
0/-0,048
> 3–6
0/-0,058
> 6–10
0/-0,070
> 10–18
0/-0,084
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
gradKe30KF3-0FC-DHCPHP
AlTiN
order # catalogue #
gradKe30KF3-0DFC-DHCPHP
AlTiN
order # catalogue #
length of cut
length
D1 D
Ap1 max
L
BCH
ZU
2342270 422822-000060
2342341 422826-000060
6,0
6
13,00
57 0,10 6
2342272 422822-000080
2342343 422826-000080
8,0
8
19,00
63 0,20 6
2342274 422822-000100 2342345 422826-000100 10,0 10
22,00
72 0,30 6
2342276 422822-000120 2342347 422826-000120 12,0 12
26,00
83 0,30 6
2342280 422822-000160 2342351 422826-000160 16,0 16
32,00
92 0,40 6
2342282 422822-000180 2342353 422826-000180 18,0 18
32,00
92 0,40 8
2342284 422822-000200 2342355 422826-000200 20,0 20
38,00
104 0,40 8
2342286 422822-000250 2342357 422826-000250 25,0 25
45,00
121 0,40 8
