High-Performance Solid Carbide End Mills • Aluminium
Series 5102 • AluSurf™
• Centre cutting.
• Wiper facet design for improved floor finishes.
• Standard items listed. Additional styles and coatings
made-to-order.
Series 5102 • AluSurf
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
graUdeNUCNOCATOEADTED
order # catalogue #
D1
length of cut
length
D Ap1 max
L
3484680 510201500..
1,5
3
6,00
38
3484681 510202000..
2,0
3
8,00
38
3484682 510202500..
2,5
3
9,00
38
3484683 510203000..
3,0
3
12,00
38
3107860 510204001..
4,0
4
12,00
50
3484684 510205001..
5,0
5
14,00
50
3484685 510205002..
5,0
6
14,00
50
3107859 510206002..
6,0
6
16,00
50
3484686 510208003..
8,0
8
20,00
63
3484687 510210004.. 10,0 10
22,00
76
3484688 510212005.. 12,0 12
25,00
76
3484689 510214014.. 14,0 14
32,00
83
3484690 510216006.. 16,0 16
32,00
89
3484691 510218018.. 18,0 18
38,00
100
3484692 510220007.. 20,0 20
38,00
104
