High-Performance Solid Carbide End Mills • Aluminium
Series D502
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series D502
gradUeNUCNOCAOTEADTED
order #
1661526
1661530
1661534
1661538
1661543
1661547
1661551
1661555
1661560
1661569
catalogue #
D50203002..
D50204002..
D50205002..
D50206002..
D50208003..
D50210004..
D50212005..
D50214014..
D50216006..
D50220007..
gradTeiATlNiA-lRNT-RT
TiAlN
order #
1602233
1602235
1602236
1661540
1602239
1602240
1602251
1602252
catalogue #
D50203002RT
D50204002RT
D50205002RT
D50206002RT
D50208003RT
D50210004RT
D50212005RT
—
D50216006RT
—
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
length of cut
length
D1 D
Ap1 max
L
3,0 6
4,00
50
4,0 6
5,00
54
5,0 6
6,00
54
6,0 6
7,00
54
8,0 8
9,00
58
10,0 10
11,00
66
12,0 12
12,00
73
14,0 14
14,00
75
16,0 16
16,00
82
20,0 20
20,00
92
