High-Performance Solid Carbide End Mills • Aluminium
Series 022814 022817
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Detail X
X
Series 022814 022817
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h10
+/-
D
0/0,040
)3
0/0,048
> 3–6
0/0,058
> 6–10
0/0,070
> 10–18
0/0,084
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
graKde10KF10F
uncoated
order # catalogue #
gradKe10KF10F
uncoated
order # catalogue #
length of cut
length
D1 D
Ap1 max
L BCH
2332369 022814-000040
2332410 022817-000040
4,0
6
8,00
57 0,10
2332370 022814-000050
2332411 022817-000050
5,0
6
10,00
57 0,10
2332371 022814-000060
2332412 022817-000060
6,0
6
10,00
57 0,10
2332372 022814-000080
2332413 022817-000080
8,0
8
16,00
63 0,10
2332373 022814-000100 2332414 022817-000100 10,0 10
19,00
72 0,10
2332374 022814-000120 2332415 022817-000120 12,0 12
22,00
83 0,20
2332375 022814-000140 2332416 022817-000140 14,0 14
22,00
83 0,20
2332376 022814-000160 2332417 022817-000160 16,0 16
26,00
92 0,20
2332377 022814-000180 2332418 022817-000180 18,0 18
26,00
92 0,20
2332378 022814-000200 2332419 022817-000200 20,0 20
32,00
104 0,20
