High-Performance Solid Carbide End Mills • Aluminium
Application Data • Series 524149
Series 524149
Side Milling (A)
and Slotting (B)
K10F-DCL
DLC
Material
Group
A
ap ae
B
Cutting Speed — vc
m/min
ap min
max
1 1,2 x D 0,5 x D
2 1,2 x D 0,5 x D
N 3 1,2 x D 0,5 x D
4 1,2 x D 0,5 x D
6 1,2 x D 0,5 x D
1xD
1xD
1xD
1xD
1xD
500 – 2000
500 – 1500
500 – 1500
250 – 750
100 – 500
NOTE: For better surface nish, reduce feed per tooth.
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
D1 — Diameter
mm ,0 4,0 5,0 6,0 8,0 10,0 12,0
fz 0,021 0,028 0,035 0,042 0,056 0,070 0,084
fz 0,019 0,025 0,032 0,038 0,050 0,063 0,076
fz 0,017 0,022 0,028 0,034 0,045 0,056 0,067
fz 0,015 0,020 0,025 0,029 0,039 0,049 0,059
fz 0,021 0,028 0,035 0,042 0,056 0,070 0,084
Application Data • Series 022849
Series 022849
Side Milling (A)
and Slotting (B)
K10F
uncoated
Material
Group
A
ap ae
B
Cutting Speed — vc
m/min
ap min
max
1 1,2 x D 0,5 x D
N
2 1,2 x D 0,5 x D
1xD
1xD
500 –
500 –
2000
1500
NOTE: For better surface nish, reduce feed per tooth.
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
D1 — Diameter
mm 2,0 3,0 4,0 5,0 6,0 8,0 10,0 12,0
fz 0,014 0,021 0,028 0,035 0,042 0,056 0,070 0,084
fz 0,011 0,017 0,022 0,028 0,034 0,045 0,056 0,067
Application Data • Series D502
Series D502
Side Milling (A)
and Slotting (B)
uncoated
TiAlN
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
Material
Group
A
ap ae
Cutting Speed Cutting Speed
B — vc
— vc
m/min
m/min
D1 — Diameter
ap min
max min
max mm 3,0 4,0 5,0 6,0 8,0 10,0 12,0 14,0 16,0 20,0
1 1,5 x D
2 1,5 x D
N 3 1,5 x D
4 1,5 x D
5 1,5 x D
0,5 x D
0,5 x D
0,5 x D
0,5 x D
0,5 x D
1xD
1xD
1xD
1xD
1xD
500 – 2000 500 – 2000 fz 0,027 0,036 0,045 0,054 0,072 0,090 0,108 0,126 0,144 0,180
500 – 1500 500 – 1500 fz 0,024 0,032 0,041 0,049 0,065 0,081 0,097 0,113 0,130 0,162
500 – 1500 500 – 1500 fz 0,019 0,025 0,032 0,038 0,050 0,063 0,076 0,088 0,101 0,126
400 – 750 400 – 750 fz 0,022 0,029 0,036 0,043 0,058 0,072 0,086 0,101 0,115 0,144
250 – 1000 250 – 1000 fz 0,024 0,032 0,041 0,049 0,065 0,081 0,097 0,113 0,130 0,162
NOTE: For cutting aluminium with high silicon, TiAlN coating is recommended.
Multiply ap for milling machine spindle with ceramic bearings by 0,5.
For better surface nish, reduce feed per tooth.
Above parameters are based on ideal conditions. For smaller taper machining centres, please adjust parameters accordingly on diameters >12mm.
