High-Performance Solid Carbide End Mills • Hard Materials
Series 70N7 • >52 HRC • Vision Plus™ X-Feed™
• Non-centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series 70N7 • >52 HRC • Vision Plus X-Feed
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
tolerance h6
D +/-
-0,014/-0,028
)3
0/0,006
-0,020/-0,038 > 3–6
0/0,008
-0,025/-0,047 > 6–10
0/0,009
-0,032/-0,059 > 10–18 0/0,011
-0,040/-0,073 > 18–30 0/0,013
first choice
alternate choice
graAdelTAiNlT-MiNT-M1 T1
AlTiN
order # catalogue #
D1 D
length of cut
D3 Ap1 max L3
length
L
R
Rt
3484756 70N706002MT
6,0
6
5,50
0,20 18,00 63 0,38 0,58
3484757 70N708003MT
8,0
8
7,50
0,27 24,00 76 0,50 0,77
3484758 70N710004MT 10,0 10
9,00
0,33 30,00 89 0,63 0,96
3403492 70N712005MT 12,0 12 11,00 0,40 36,00 100 0,75 1,15
3477329 70N716006MT 16,0 16 15,00 0,54 48,00 110 1,00 1,54
3484759 70N720007MT 20,0 20 19,00 0,67 60,00 125 1,25 1,92
NOTE: YRC = distance from centre line to the crown of the R radius.
RCN = distance from centre line to the start of the cutting edge. This dimension can also help determine the minimum circle size when helical ramping.
R = the head radius size.
R = the shoulder radius or radius at the corner of the cutter.
Programming Data
Tool List 70N7
Ramping Guide for Circular and Linear Interpolation
Geometrical Parameters
Circular Interpolation
Linear Interpolation
diameter
[mm]
6
8
10
12
16
20
Ap1 max
[mm]
0,20
0,27
0,33
0,40
0,54
0,67
Rfm
[mm]
9
12
15
18
24
30
Rt
[mm]
0,58
0,77
0,96
1,15
1,54
1,92
Rc Xfm Yfm
[mm] [mm] [mm]
0,375 0,20 0,75
0,500 0,27 1,00
0,625 0,33 1,25
0,750 0,40 1,50
1,000 0,54 2,00
1,250 0,67 2,50
Recommended Feed
YD
[mm]
1,26
1,68
2,10
2,52
3,36
4,20
Number
utes
6
6
6
6
6
div class="txt" style="position:absolute; left:321px; top:748px;">6
Allowed Range of
Hole Diameter
Calculated Length (mm) per Ramp Angle
Ramp Angle (degree)
Smallest Largest 1 2 3 4 5
8,52 12 11,51 5,75 3,83 2,87 2,30
11,36
16 15,34 7,67 5,11 3,83 3,06
14,2 20 19,18 9,58 6,39 4,79 3,83
17,04
24 23,01 11,50 7,66 5,74 4,59
22,72
32 30,68 15,34 10,22 7,66 6,12
28,4 40 38,35 19,17 12,77 9,57 7,65
100% 70% 50% 30% 10%
