High-Performance Solid Carbide End Mills • Hard Materials
Series 422876 422878 • Vision Plus™
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series 422876 422878 • Vision Plus
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h8
+/-
D
0/0,014
)3
0/0,018
> 3–6
0/0,022
> 6–10
0/0,027
> 10–18
0/0,033
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
graKde10KU1F0-UDFC-HDPCHP
AlTiN
order # catalogue #
D1 D
length of cut
length
D3 Ap1 max L3
L R
2628898 422876-004005
4,0
6
3,80
4,00 10,00 45 0,50
2629013 422876-004010
4,0
6
3,80
4,00 10,00 45 1,00
2629015 422876-005005
5,0
6
4,80
5,00 12,00 50 0,50
2629016 422876-005010
5,0
6
4,80
5,00 12,00 50 1,00
2629018 422876-006005
6,0
6
5,80
6,00 12,00 50 0,50
2629021 422876-006010
6,0
6
5,80
6,00 12,00 50 1,00
2630276 422878-006005
6,0
6
5,80
6,00 42,00 80 0,50
2629056 422876-008005
8,0
8
7,80
8,00 20,00 60 0,50
2629060 422876-008010
8,0
8
7,80
8,00 20,00 60 1,00
2629061 422876-008020
8,0
8
7,80
8,00 20,00 60 2,00
2630285 422878-008010
8,0
8
7,80
8,00 51,00 90 1,00
2630288 422878-008015
8,0
8
7,80
8,00 51,00 90 1,50
2630290 422878-008020
8,0
8
7,80
8,00 51,00 90 2,00
2629062 422876-010005 10,0 10
9,80
10,00
26,00 70 0,50
2629077 422876-010010 10,0 10
9,80
10,00
26,00 70 1,00
2629086 422876-010020 10,0 10
9,80
10,00
26,00 70 2,00
2630291 422878-010005 10,0 10
9,70
10,00
57,00 100 0,50
2630292 422878-010010 10,0 10
9,70
10,00
57,00 100 1,00
2630345 422878-010020 10,0 10
9,70
10,00
57,00 100 2,00
2629089 422876-012005 12,0 12 11,80
12,00
26,00 75 0,50
2629094 422876-012010 12,0 12 11,80
12,00
26,00 75 1,00
2629095 422876-012020 12,0 12 11,80
12,00
26,00 75 2,00
2629097 422876-012030 12,0 12 11,80
12,00
26,00 75 3,00
2630347 422878-012010 12,0 12 11,70
12,00
62,00 110 1,00
2630386 422878-012030 12,0 12 11,70
12,00
62,00 110 3,00
