High-Performance Solid Carbide End Mills • Hard Materials
Series 422837 422831 • Vision Plus™
• Non-centre cutting.
• Standard items listed. Additional styles and
coatings made-to-order.
Series 422837 422831 • Vision Plus
gradKe10KU1F0-UDFC-DHCPHP
AlTiN
order # catalogue #
D1 D
2342495 422837-006005
6,0
6
2342388 422831-006005
6,0
6
2342497 422837-008005
8,0
8
2342390 422831-008005
8,0
8
2342499 422837-010005 10,0 10
2342392 422831-010005 10,0 10
2656458 422837-012005 12,0 12
2342501 422837-012010 12,0 12
2657057 422831-012005 12,0 12
2342394 422831-012010 12,0 12
2656459 422837-016005 16,0 16
2342502 422837-016010 16,0 16
2342396 422831-016010 16,0 16
2657058 422831-016005 16,0 16
2656460 422837-020005 20,0 20
2342505 422837-020010 20,0 20
2342398 422831-020010 20,0 20
2656461 422837-025005 25,0 25
2342400 422831-025015 25,0 25
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h10
+/-
D
0/0,040
)3
0/0,048
> 3–6
0/0,058
> 6–10
0/0,070
> 10–18
0/0,084
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
length of cut
length
Ap1 max
L R ZU
13,00
57 0,50 6
18,00
62 0,50 6
19,00
63 0,50 6
24,00
68 0,50 6
22,00
72 0,50 6
30,00
80 0,50 6
26,00
83 0,50 6
26,00
83 1,00 6
36,00
93 0,50 6
36,00
93 1,00 6
32,00
92 0,50 6
32,00
92 1,00 6
48,00
108 1,00 6
48,00
108 0,50 6
38,00
104 0,50 8
38,00
104 1,00 8
60,00
126 1,00 8
45,00
121 0,50 8
75,00
150 1,50 8
