High-Performance Solid Carbide End Mills • Hard Materials
Series 7670 • Vision Plus™
• Centre cutting.
• Standard items listed. Additional styles and
coatings made-to-order.
Series 7670 • Vision Plus
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance d11
-0,020/-0,080
-0,030/-0,105
-0,040/-0,130
-0,050/-0,160
-0,065/-0,195
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
graTdieAlTNiA-lNLT-L1T1
TiAlN
order #
1724582
1724556
1724558
1724559
1724560
1724590
1724621
1724622
1806404
catalogue #
767004002LT
767005002LT
767006004LT
767008004LT
767010005LT
767012006LT
767016006LT
767020007LT
767025008LT
length of cut
length
D1 D
D3
Ap1 max
L3
L R ZU BETA
4,0 6
—
4,00
4,00
75
0,75 3
2.5
5,0 6
—
5,00
5,00
75
0,75 3
2.5
6,0 10
—
6,00 6,00 100 0,75 4 2.5
8,0 10
—
8,00 8,00 100 0,75 4 2.5
10,0 12
—
10,00
10,00 125 0,75 4 2.5
12,0 16
—
12,00
12,00 125 1,00 4 2.5
16,0 16 15,00
16,00
48,00 125 1,00 6
—
20,0 20 19,00
20,00
60,00 150 1,25 6
—
25,0 25 24,00
25,00
75,00 150 1,25 6
—
