High-Performance Solid Carbide End Mills • Hard Materials
Application Data • Series 75N2 • Vision Plus™
Series 75N2 • Vision Plus
Side Milling (A)
and Slotting (B)
TiAlN
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
Material
Group
A
ap
ae
B
Cutting Speed — vc
m/min
D1 — Diameter
ap min
max mm 3,0 4,0 5,0 6,0 8,0 10,0 12,0
3 0,75 x D
P
4 0,75 x D
0,1 x D 0,4 x D 160 – 180
0,1 x D 0,4 x D 140 – 160
fz 0,017 0,023 0,030 0,036 0,050 0,061 0,070
fz 0,016 0,021 0,027 0,033 0,045 0,054 0,062
1 0,75 x D 0,1 x D 0,4 x D 120 – 140 fz 0,016 0,021 0,027 0,033 0,045 0,054 0,062
2 0,75 x D 0,05 x D 0,3 x D 100 – 130
H
3 0,75 x D 0,03 x D 0,2 x D 70 – 100
fz 0,016 0,020 0,025 0,029 0,034 0,037 0,040
fz 0,013 0,016 0,019 0,023 0,026 0,029 0,032
4 0,75 x D 0,01 x D 0,1 x D 50 – 70
fz 0,008 0,011 0,013 0,015 0,018 0,019 0,021
NOTE: Lower value of cutting speed is used for high stock removal applications or for higher hardness (machinability) within group.
Higher value of cutting speed is used for nishing applications or for lower hardness (machinability) within group.
Application Data • Series 422875 • Vision Plus™
Series 422875 • Vision Plus
Side Milling (A)
and Slotting (B)
K10UF-DCHP
AlTiN
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
Material
Group
3
P
4
A
ap
0,5 x D
0,5 x D
ae
0,4 x D
0,4 x D
B
ap
0,3 x D
0,3 x D
Cutting Speed — vc
m/min
min max
108 – 144
81 – 135
D1 — Diameter
mm 3,0 4,0 5,0 6,0 8,0 10,0 12,0
fz 0,017 0,023 0,030 0,036 0,050 0,061 0,070
fz 0,016 0,021 0,027 0,033 0,045 0,054 0,062
1
2
H
3
4
0,5 x D
0,5 x D
0,5 x D
0,5 x D
0,4 x D 0,3 x D 72 – 126
0,3 x D 0,2 x D 63 – 108
0,15 x D 0,15 x D 54 – 81
0,1 x D 0,1 x D 45 – 63
fz 0,016 0,021 0,027 0,033 0,045 0,054 0,062
fz 0,012 0,016 0,020 0,025 0,034 0,040 0,047
fz 0,009 0,013 0,016 0,019 0,026 0,032 0,037
fz 0,006 0,008 0,011 0,013 0,018 0,021 0,025
NOTE: Lower value of cutting speed is used for high stock removal applications or for higher hardness (machinability) within group.
Higher value of cutting speed is used for nishing applications or for lower hardness (machinability) within group.
For ap/ae 0.05 x D, increase fz by 40%.
For better surface nish, reduce feed per tooth.
