High-Performance Solid Carbide End Mills • Hard Materials
Application Data • Series 75N5 • Vision Plus™
Series 75N5 • Vision Plus
Side Milling (A)
and Slotting (B)
TiAlN
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
Material
Group
A
ap ae
Cutting Speed
B — vc
m/min
D1 — Diameter
ap min max mm 4,0 5,0 6,0 8,0 10,0 12,0 14,0 16,0 18,0 20,0 25,0
3
P
4
1xD
1xD
0,4 x D 1 x D 120 – 160 fz 0,026 0,033 0,040 0,055 0,067 0,077 0,087 0,096 0.,104 0,111 0,125
0,4 x D 0,75 x D 90 – 150 fz 0,024 0,030 0,036 0,049 0,059 0,069 0,077 0,084 0,091 0,097 0,107
1 1 x D 0,4 x D 0,75 x D 80 – 140 fz 0,024 0,030 0,036 0,049 0,059 0,069 0,077 0,084 0,091 0,097 0,107
2
H
3
1xD
1xD
0,3 x D 0,5 x D
0,15 x D 0,3 x D
70 – 120 fz 0,018 0,022 0,027 0,037 0,044 0,051 0,057 0,063 0,067 0,071 0,078
60 – 90 fz 0,014 0,018 0,021 0,029 0,035 0,041 0,046 0,051 0,055 0,059 0,067
4 1 x D 0,1 x D 0,15 x D 50 – 70 fz 0,009 0,012 0014 0,019 0,023 0,027 0,031 0,034 0,037 0,039 0,044
NOTE: Lower value of cutting speed is used for high stock removal applications or for higher hardness (machinability) within group.
Higher value of cutting speed is used for nishing applications or for lower hardness (machinability) within group.
For better surface nish, reduce feed per tooth.
Application Data • Series 75N8 • Vision Plus™
Series 75N8 • Vision Plus
Side Milling (A)
and Slotting (B)
TiAlN
Recommended feed per tooth (fz = mm/th) for side milling (A).
For slotting (B), reduce fz by 20%.
Material
Group
A
ap ap
B
Cutting Speed — vc
m/min
ap min
max mm
6,0
D1 — Diameter
8,0 10,0
12,0
3 0,75 x D 0,2 x D 0,2 x D
P
4 0,75 x D 0,2 x D 0,2 x D
120 –
90 –
160
150
fz
fz
0,040
0,036
0,055
0,049
0,067
0,059
0,077
0,069
1 0,75 x D 0,2 x D 0,2 x D 80 – 140
fz
0,036
0,049
0,059
0,069
2 0,75 x D 0,2 x D 0,2 x D
H
3 0,75 x D 0,1 x D 0,1 x D
70 – 120
60 – 90
fz
fz
0,027
0,021
0,037
0,029
0,044
0,035
0,051
0,041
4 0,75 x D 0,05 x D 0,05 x D 50 – 70
fz
0,014
0,019
0,023
0,027
NOTE: Lower value of cutting speed is used for high stock removal applications or for higher hardness (machinability) within group.
Higher value of cutting speed is used for nishing applications or for lower hardness (machinability) within group.
For better surface nish, reduce feed per tooth.
