General Purpose Solid Carbide End Mills • Roughing/Finishing
Series 2528 • VariMill™ GP
• Centre cutting.
• Chamfered corners.
• Standard items listed. Additional styles
and coatings made-to-order.
Detail X
Series 2528 • VariMill GP
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
grUaNdeCOUNATCEODAT- E..D
order # catalogue #
gradTeiATlNiAlN
TiAlN
order # catalogue #
length of cut
length
D1 D
Ap1 max
L BCH
5825993 25280400T011
5825978 25280400T011
4,0
4
11,00
50 0,10
5825994 25280500T013
5825979 25280500T013
5,0
5
13,00
50 0,10
5825995 25280600T013
5825980 25280600T013
6,0
6
13,00
57 0,10
5825996 25280800T019
5825981 25280800T019
8,0
8
19,00
63 0,20
5825997 25281000T022 5825982 25281000T022 10,0 10
22,00
72 0,20
5825988 25281200T026 5825983 25281200T026 12,0 12
26,00
83 0,30
5825989 25281400T026 5825984 25281400T026 14,0 14
26,00
83 0,30
5825990 25281600T032 5825985 25281600T032 16,0 16
32,00
92 0,30
5825991 25281800T032 5825986 25281800T032 18,0 18
32,00
92 0,30
5825992 25282000T038 5825987 25282000T038 20,0 20
38,00
104 0,30
NOTE: For application data, please see page P41.
