General Purpose Solid Carbide End Mills • Roughing/Finishing
Series 4000 4010 • VariMill™ GP
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series 4000 4010 • VariMill GP
graTdieATlNiAlN
TiAlN
order # catalogue #
5825555 40000200T006
5825556 40000300T020
5825557 40000400T014
5825558 40100400T025
5825559 40000500T016
5825560 40100500T030
5825573 40000600T016
5825574 40100600T019
5825575 40100600T030
5825576 40000800T019
5825577 40100800T040
5825578 40001000T022
5825579 40101000T040
5825580 40001200T025
5825581 40101200T045
5825583 40001400T032
5825584 40101400T050
5825585 40001600T032
5825586 40101600T065
5825587 40001800T038
5825588 40102000T056
NOTE: For application data, please see pages P42–P43.
D1
2,0
3,0
4,0
4,0
5,0
5,0
6,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
12,0
14,0
14,0
16,0
16,0
18,0
20,0
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
length of cut
length
D Ap1 max
L
3 6,30
38
3 20,00
75
4 14,00
50
4 25,00
75
5 16,00
50
5 30,00
75
6 16,00
50
6 19,00
63
6 30,00
75
8 19,00
63
8 40,00
100
10 22,00
72
10 40,00
100
12 25,00
75
12 45,00
150
14 32,00
83
14 50,00
100
16 32,00
89
16 65,00
150
18 38,00
100
20 56,00
125
