Modular Drills
Chamfering and Countersinking Order Planning
Please utilise guide below to plan your TOP DRILL M1™ modular step drill based
on your needs and requirements. Please contact your distributor for a quote.
Option 1 TOP DRILL M1 Drilling and Chamfering
Overall Length
Drill Length
Shank Diameter
[L]
[L1]
[D]
Drill Diameter Min
Drilling Depth
Cutting Diameter 2 Angle
Chamfering Depth
[D1]
[DD]
m
[CD]
Option 2 TOP DRILL M1 Drilling and Countersinking
Overall Length
Drill Length
Shank Diameter
[L]
[L1]
[D]
Drill Diameter Min
Drilling Depth
Cut Diameter 23
Countersinking Depth
Cutting Diameter 2 Angle
[D1]
[DD]
[D23]
[DD1]
m
