WIDIA - Полный каталог инструмента - 2017
Indexable Drills
Top Cut 4™ Shanks
для размещения заказа - zakaz@widiahanita.ru
For information on LS, see the table on page V10.
Top Cut 4 Drill • Metric • 2 x D • SL Shanks
order number catalogue number D1 D1 max D L1 L4 max L5
5537778
TCF120R2SL20MA 12,00 12,50 20 54,6
24,0 0,41
5537779
TCF125R2SL20MA 12,50 13,00 20 55,8
25,0 0,48
5537860
TCF127R2SL20MA 12,70 13,20 20 56,2
26,0 0,51
5537861
TCF130R2SL20MA 13,00 13,50 20 56,9
26,0 0,56
5537862
TCF135R2SL20MA 13,50 14,00 20 58,1
27,0 0,64
5577828
TCF140R2SL25MB 14,00 14,50 25 59,8
28,0 0,42
5577829
TCF145R2SL25MB 14,50 15,00 25 60,9
29,0 0,45
5577920
TCF150R2SL25MB 15,00 15,50 25 62,1
30,0 0,49
5577921
TCF155R2SL25MB 15,50 16,00 25 63,3
31,0 0,54
5577922
TCF160R2SL25MB 16,00 16,50 25 64,4
32,0 0,60
5577923
TCF165R2SL25MB 16,50 17,00 25 65,6
33,0 0,68
5577924
TCF170R2SL25MB 17,00 17,50 25 68,4
34,0 0,74
5577925
TCF175R2SL25MB 17,50 18,00 25 69,6
35,0 0,79
5577926
TCF180R2SL25MB 18,00 18,50 25 70,8
36,0 0,86
5577927
TCF185R2SL25MB 18,50 19,00 25 71,9
37,0 0,83
5578820
TCF190R2SL25MC 19,00 19,50 25 72,1
38,0 0,60
5578821
TCF195R2SL25MC 19,50 20,00 25 73,2
39,0 0,70
5578822
TCF200R2SL25MC 20,00 20,50 25 74,4
40,0 0,70
5578823
TCF205R2SL25MC 20,50 21,00 25 75,6
41,0 0,70
5578824
TCF210R2SL25MC 21,00 21,50 25 76,7
42,0 0,80
5578825
TCF220R2SL25MC 22,00 22,50 25 79,0
44,0 1,00
5578826
TCF225R2SL25MC 22,50 23,00 25 80,2
45,0 1,10
5578827
TCF230R2SL25MC 23,00 23,50 25 81,4
46,0 1,10
5537167
TCF240R2SL25MD 24,00 25,00 25 87,2
48,0 0,78
5537168
TCF250R2SL32MD 25,00 26,00 32 89,6
50,0 0,86
5537169
TCF260R2SL32MD 26,00 27,00 32 91,9
52,0 0,97
5537820
TCF265R2SL32MD 26,50 27,50 32 93,0
53,0 1,05
5537821
TCF270R2SL32MD 27,00 28,00 32 94,2
54,0 1,15
5537822
TCF280R2SL32MD 28,00 29,00 32 96,5
56,0 1,30
5537823
TCF290R2SL32MD 29,00
30,00
32 98,8
58,0 1,45
5537937
TCF300R2SL32ME 30,00 31,00 32 100,2 60,0 0,63
5537938
TCF310R2SL32ME 31,00 32,00 32 102,5 62,0 0,72
insert
size
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
C
C
C
C
C
C
C
C
D
D
D
D
D
D
D
E
E
periphery
insert
TCF040204AP
TCF040204AP
TCF040204AP
TCF040204AP
TCF040204AP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF100408EP
TCF100408EP
centre
insert
TCF040203AC
TCF040203AC
TCF040203AC
TCF040203AC
TCF040203AC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF120405EC
TCF120405EC
(continued)
V8
