Indexable Drills
Top Cut 4™ Shanks
(Top Cut 4 Drill • Metric • 2 x D • SL Shanks — continued)
order number catalogue number D1 D1 max D L1 L4 max L5
5537939
TCF320R2SL32ME 32,00 33,00 32 104,8 64,0 0,82
5537940
TCF330R2SL40ME 33,00 34,00 40 107,1 66,0 0,95
5537941
TCF340R2SL40ME 34,00 35,00 40 109,4 68,0 1,14
5537942
TCF350R2SL40ME 35,00 36,00 40 111,8 70,0 1,30
5537943
TCF360R2SL40ME 36,00 37,00 40 114,1 72,0 1,45
5578539
TCF370R2SL40MF 37,00 38,00 40 118,1 74,0 1,19
5578600
TCF375R2SL40MF 37,50 38,50 40 119,3 75,0 1,23
5578601
TCF380R2SL40MF 38,00 39,00 40 120,5 76,0 1,27
5578602
TCF390R2SL40MF 39,00 40,00 40 122,8 78,0 1,36
5578603
TCF400R2SL40MF 40,00 41,00 40 125,1 80,0 1,47
5578604
TCF410R2SL40MF 41,00 42,00 40 127,4 82,0 1,60
5578605
TCF420R2SL40MF 42,00 43,00 40 129,7 84,0 1,77
5578606
TCF430R2SL40MF 43,00 44,00 40 132,1 86,0 1,99
5578607
TCF440R2SL40MF 44,00 45,00 40 134,4 88,0 2,10
5578608
TCF450R2SL50MF 45,00 46,00 50 136,7 90,0 2,21
5578694
TCF460R2SL50MG 46,00 47,00 50 139,0 92,0 1,45
5578695
TCF470R2SL50MG 47,00 48,00 50 141,3 94,0 1,53
5578696
TCF480R2SL50MG 48,00 49,00 50 143,7 96,0 1,63
5578697
TCF490R2SL50MG 49,00 50,00 50 146,0 98,0 1,74
5578698
TCF500R2SL50MG 50,00 51,00 50 149,8 100,0 1,87
5578699
TCF505R2SL50MG 50,50 51,50 50 151,0 101,0 1,94
5578710
TCF510R2SL50MG 51,00 52,00 50 152,1 102,0 2,02
5578711
TCF520R2SL50MG 52,00 53,00 50 154,4 104,0 2,22
5578712
TCF530R2SL50MG 53,00 54,00 50 156,8 106,0 2,46
5578713
TCF540R2SL50MG 54,00 55,00 50 159,1 108,0 2,53
5578714
TCF550R2SL50MG 55,00 56,00 50 161,4 110,0 2,73
5578715
TCF560R2SL50MG 56,00 57,00 50 163,7 112,0 2,37
5538613
TCF570R2SL50MH 57,00 58,00 50 165,5 114,0 1,76
5538614
TCF580R2SL50MH 58,00 59,00 50 167,9 116,0 1,85
5538615
TCF590R2SL50MH 59,00 60,00 50 170,2 118,0 1,96
5538616
TCF600R2SL50MH 60,00 61,00 50 172,5 120,0 1,42
5538617
TCF610R2SL50MH 61,00 62,00 50 174,8 122,0 2,23
5538618
TCF620R2SL50MH 62,00 63,00 50 177,1 124,0 2,41
5538619
TCF630R2SL50MH 63,00 64,00 50 179,5 126,0 2,64
5538630
TCF640R2SL50MH 64,00 65,00 50 181,8 128,0 2,94
5538631
TCF650R2SL50MH 65,00 66,00 50 184,1 130,0 3,06
5538632
TCF660R2SL50MH 66,00 67,00 50 186,4 132,0 3,18
5538633
TCF670R2SL50MH 67,00 68,00 50 188,7 134,0 3,30
5538634
TCF680R2SL50MH 68,00 69,00 50 191,1 136,0 2,93
insert
size
E
E
E
E
E
F
F
F
F
F
F
F
F
F
F
G
G
G
G
G
G
G
G
G
G
G
G
H
H
H
H
H
H
H
H
H
H
H
H
periphery
insert
TCF100408EP
TCF100408EP
TCF100408EP
TCF100408EP
TCF100408EP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
centre
insert
TCF120405EC
TCF120405EC
TCF120405EC
TCF120405EC
TCF120405EC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
(continued)
