Indexable Drills
Top Cut 4™ Shanks
For information on LS, see the table on page V13.
Top Cut 4 Drill • Metric • 3 x D • SL Shanks
order number catalogue number D1 D1 max D L1 L4 max L5
5537863
TCF120R3SL20MA 12,00 12,50 20 66,6
36,0 0,41
5537864
TCF125R3SL20MA 12,50 13,00 20 68,3
37,5 0,48
5537866
TCF127R3SL20MA 12,70 13,20 20 68,9
38,1 0,51
5537867
TCF130R3SL20MA 13,00 13,50 20 69,9
39,0 0,56
5537868
TCF135R3SL20MA 13,50 14,00 20 71,6
41,0 0,64
5577928
TCF140R3SL25MB 14,00 14,50 25 73,8
42,0 0,42
5577929
TCF145R3SL25MB 14,50 15,00 25 75,4
43,5 0,45
5577930
TCF150R3SL25MB 15,00 15,50 25 77,1
45,0 0,49
5577931
TCF155R3SL25MB 15,50 16,00 25 78,8
46,5 0,54
5577932
TCF160R3SL25MB 16,00 16,50 25 80,4
48,0 0,60
5577933
TCF165R3SL25MB 16,50 17,00 25 82,1
49,5 0,68
5577934
TCF170R3SL25MB 17,00 17,50 25 85,4
51,0 0,74
5577935
TCF175R3SL25MB 17,50 18,00 25 87,1
52,5 0,79
5577936
TCF180R3SL25MB 18,00 18,50 25 88,8
54,0 0,86
5577937
TCF185R3SL25MB 18,50 19,00 25 90,4
55,5 0,83
5578828
TCF190R3SL25MC 19,00 19,50 25 91,1
57,0 0,60
5578829
TCF195R3SL25MC 19,50 20,00 25 92,7
58,5 0,70
5578830
TCF200R3SL25MC 20,00 20,50 25 94,4
60,0 0,70
5578831
TCF205R3SL25MC 20,50 21,00 25 96,1
61,5 0,70
5578832
TCF210R3SL25MC 21,00 21,50 25 97,7
63,0 0,80
5578833
TCF220R3SL25MC 22,00 22,50 25 101,0 66,0 1,00
5578834
TCF225R3SL25MC 22,50 23,00 25 102,7 67,5 1,10
5578835
TCF230R3SL25MC 23,00 23,50 25 104,4 69,0 1,10
5537824
TCF240R3SL25MD 24,00 25,00 25 111,2 72,0 0,78
5537825
TCF250R3SL32MD 25,00 26,00 32 114,6 75,0 0,86
5537826
TCF260R3SL32MD 26,00 27,00 32 117,9 78,0 0,97
5537827
TCF265R3SL32MD 26,50 27,50 32 119,5 79,5 1,05
5537828
TCF270R3SL32MD 27,00 28,00 32 121,2 81,0 1,15
5537829
TCF280R3SL32MD 28,00 29,00 32 124,5 84,0 1,30
5537830
TCF290R3SL32MD 29,00 30,00 32 127,8 87,0 1,45
5537944
TCF300R3SL32ME 30,00 31,00 32 130,2 90,0 0,63
5537945
TCF310R3SL32ME 31,00 32,00 32 133,5 93,0 0,72
insert
size
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
C
C
C
C
C
C
C
C
D
D
D
D
D
D
D
E
E
periphery
insert
TCF040204AP
TCF040204AP
TCF040204AP
TCF040204AP
TCF040204AP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF100408EP
TCF100408EP
centre
insert
TCF040203AC
TCF040203AC
TCF040203AC
TCF040203AC
TCF040203AC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF120405EC
TCF120405EC
(continued)
