Indexable Drills
Top Cut 4™ Shanks
для размещения заказа - zakaz@widiahanita.ru
(Top Cut 4 Drill • Metric • 3 x D • SL Shanks — continued)
order number catalogue number D1 D1 max D L1 L4 max L5
5537946
TCF320R3SL32ME 32,00 33,00 32 136,8 96,0 0,82
5537947
TCF330R3SL40ME 33,00 34,00 40 140,1 99,0 0,95
5537948
TCF340R3SL40ME 34,00 35,00 40 143,4 102,0 1,14
5537949
TCF350R3SL40ME 35,00 36,00 40 146,8 105,0 1,30
5537950
TCF360R3SL40ME 36,00 37,00 40 150,1 108,0 1,45
5578609
TCF370R3SL40MF 37,00 38,00 40 155,1 111,0 1,19
5578610
TCF375R3SL40MF 37,50 38,50 40 156,8 113,0 1,23
5578611
TCF380R3SL40MF 38,00 39,00 40 158,5 114,0 1,27
5578612
TCF390R3SL40MF 39,00 40,00 40 161,8 117,0 1,36
5578613
TCF400R3SL40MF 40,00 41,00 40 165,1 120,0 1,47
5578614
TCF410R3SL40MF 41,00 42,00 40 168,4 123,0 1,60
5578615
TCF420R3SL40MF 42,00 43,00 40 171,7 126,0 1,77
5578616
TCF430R3SL40MF 43,00 44,00 40 175,1 129,0 1,99
5578617
TCF440R3SL40MF 44,00 45,00 40 178,4 132,0 2,10
5578618
TCF450R3SL50MF 45,00 46,00 50 181,7 135,0 2,21
5578716
TCF460R3SL50MG 46,00 47,00 50 185,0 138,0 1,45
5578717
TCF470R3SL50MG 47,00 48,00 50 188,3 141,0 1,53
5578718
TCF480R3SL50MG 48,00 49,00 50 191,7 144,0 1,63
5578719
TCF490R3SL50MG 49,00 50,00 50 195,0 147,0 1,74
5578720
TCF500R3SL50MG 50,00 51,00 50 199,8 150,0 1,87
5578721
TCF505R3SL50MG 50,50 51,50 50 201,5 152,0 1,94
5578722
TCF510R3SL50MG 51,00 52,00 50 203,1 153,0 2,02
5578723
TCF520R3SL50MG 52,00 53,00 50 206,4 156,0 2,22
5578724
TCF530R3SL50MG 53,00 54,00 50 209,8 159,0 2,46
5578726
TCF540R3SL50MG 54,00 55,00 50 213,1 162,0 2,53
5578727
TCF550R3SL50MG 55,00 56,00 50 216,4 165,0 2,73
5578728
TCF560R3SL50MG 56,00 57,00 50 219,7 168,0 2,37
5538635
TCF570R3SL50MH 57,00 58,00 50 222,5 171,0 1,76
5538636
TCF580R3SL50MH 58,00 59,00 50 225,9 174,0 1,85
5538637
TCF590R3SL50MH 59,00 60,00 50 229,2 177,0 1,96
5538638
TCF600R3SL50MH 60,00 61,00 50 232,5 180,0 1,42
5538639
TCF610R3SL50MH 61,00 62,00 50 235,8 183,0 2,23
5538640
TCF620R3SL50MH 62,00 63,00 50 239,1 186,0 2,41
5538641
TCF630R3SL50MH 63,00 64,00 50 242,5 189,0 2,64
5538642
TCF640R3SL50MH 64,00 65,00 50 245,8 192,0 2,94
5538643
TCF650R3SL50MH 65,00 66,00 50 249,1 195,0 3,06
5538644
TCF660R3SL50MH 66,00 67,00 50 252,4 198,0 3,18
5538645
TCF670R3SL50MH 67,00 68,00 50 255,7 201,0 3,30
5538646
TCF680R3SL50MH 68,00 69,00 50 259,1 204,0 2,93
insert
size
E
E
E
E
E
F
F
F
F
F
F
F
F
F
F
G
G
G
G
G
G
G
G
G
G
G
G
H
H
H
H
H
H
H
H
H
H
H
H
periphery
insert
TCF100408EP
TCF100408EP
TCF100408EP
TCF100408EP
TCF100408EP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
centre
insert
TCF120405EC
TCF120405EC
TCF120405EC
TCF120405EC
TCF120405EC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
(continued)
