Indexable Drills
Top Cut 4™ Shanks
для размещения заказа - zakaz@widiahanita.ru
For information on LS, see the table on page V16.
Top Cut 4 Drill • Metric • 4 x D • SL Shanks
order number catalogue number D1 D1 max D L1 L4 max L5
5537869
TCF120R4SL20MA 12,00 12,50 20 78,6
48,0 0,41
5537870
TCF125R4SL20MA 12,50 13,00 20 80,8
50,0 0,48
5537871
TCF127R4SL20MA 12,70 13,20 20 81,6
50,8 0,51
5537872
TCF130R4SL20MA 13,00 13,50 20 82,9
52,0 0,56
5537873
TCF135R4SL20MA 13,50 14,00 20 85,1
54,0 0,64
5577938
TCF140R4SL25MB 14,00 14,50 25 87,8
56,0 0,42
5577939
TCF145R4SL25MB 14,50 15,00 25 89,9
58,0 0,45
5577940
TCF150R4SL25MB 15,00 15,50 25 92,1
60,0 0,49
5577941
TCF155R4SL25MB 15,50 16,00 25 94,3
62,0 0,54
5577942
TCF160R4SL25MB 16,00 16,50 25 96,4
64,0 0,60
5577943
TCF165R4SL25MB 16,50 17,00 25 98,6
66,0 0,68
5577944
TCF170R4SL25MB 17,00 17,50 25 102,4 68,0 0,74
5577945
TCF175R4SL25MB 17,50 18,00 25 104,6 70,0 0,79
5577946
TCF180R4SL25MB 18,00 18,50 25 106,8 72,0 0,86
5577947
TCF185R4SL25MB 18,50 19,00 25 108,9 74,0 0,83
5578836
TCF190R4SL25MC 19,00 19,50 25 110,1 76,0 0,60
5578837
TCF195R4SL25MC 19,50 20,00 25 112,2 78,0 0,70
5578838
TCF200R4SL25MC 20,00 20,50 25 114,4 80,0 0,70
5578839
TCF205R4SL25MC 20,50 21,00 25 116,6 82,0 0,70
5578840
TCF210R4SL25MC 21,00 21,50 25 118,7 84,0 0,80
5578841
TCF220R4SL25MC 22,00 22,50 25 123,0 88,0 1,00
5578842
TCF225R4SL25MC 22,50 23,00 25 125,2 90,0 1,10
5578843
TCF230R4SL25MC 23,00 23,50 25 127,4 92,0 1,10
5537831
TCF240R4SL25MD 24,00 25,00 25 135,2 96,0 0,78
5537832
TCF250R4SL32MD 25,00 26,00 32 139,6 100,0 0,86
5537833
TCF260R4SL32MD 26,00 27,00 32 143,9 104,0 0,97
5537834
TCF265R4SL32MD 26,50 27,50 32 146,0 106,0 1,05
5537835
TCF270R4SL32MD 27,00 28,00 32 148,2 108,0 1,15
5537836
TCF280R4SL32MD 28,00 29,00 32 152,5 112,0 1,30
5537837
TCF290R4SL32MD 29,00 30,00 32 156,8 116,0 1,45
5537951
TCF300R4SL32ME 30,00
31,00
32 160,2
120,0
0,63
5537952
TCF310R4SL32ME 31,00
32,00
32 164,5
124,0
0,72
insert
size
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
C
C
C
C
C
C
C
C
D
D
D
D
D
D
D
E
E
periphery
insert
TCF040204AP
TCF040204AP
TCF040204AP
TCF040204AP
TCF040204AP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF100408EP
TCF100408EP
centre
insert
TCF040203AC
TCF040203AC
TCF040203AC
TCF040203AC
TCF040203AC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF120405EC
TCF120405EC
(continued)
V14
