Indexable Drills
Top Cut 4™ Shanks
(Top Cut 4 Drill • Metric • 4 x D • SL Shanks — continued)
order number catalogue number D1 D1 max D L1 L4 max L5
5537953
TCF320R4SL32ME 32,00 33,00 32 168,8 128,0 0,82
5537954
TCF330R4SL40ME 33,00 34,00 40 173,1 132,0 0,95
5537955
TCF340R4SL40ME 34,00 35,00 40 177,4 136,0 1,14
5537956
TCF350R4SL40ME 35,00 36,00 40 181,8 140,0 1,30
5537957
TCF360R4SL40ME 36,00 37,00 40 186,1 144,0 1,45
5578619
TCF370R4SL40MF 37,00 38,00 40 192,1 148,0 1,19
5578620
TCF375R4SL40MF 37,50 38,50 40 194,3 150,0 1,23
5578621
TCF380R4SL40MF 38,00 39,00 40 196,5 152,0 1,27
5578622
TCF390R4SL40MF 39,00 40,00 40 200,8 156,0 1,36
5578623
TCF400R4SL40MF 40,00 41,00 40 205,1 160,0 1,47
5578624
TCF410R4SL40MF 41,00 42,00 40 209,4 164,0 1,60
5578625
TCF420R4SL40MF 42,00 43,00 40 213,7 168,0 1,77
5578626
TCF430R4SL40MF 43,00 44,00 40 218,1 172,0 1,99
5578627
TCF440R4SL40MF 44,00 45,00 40 222,4 176,0 2,10
5578628
TCF450R4SL50MF 45,00 46,00 50 226,7 180,0 2,21
5578729
TCF460R4SL50MG 46,00 47,00 50 231,0 184,0 1,45
5578730
TCF470R4SL50MG 47,00 48,00 50 235,3 188,0 1,53
5578731
TCF480R4SL50MG 48,00 49,00 50 239,7 192,0 1,63
5578732
TCF490R4SL50MG 49,00 50,00 50 244,0 196,0 1,74
5578733
TCF500R4SL50MG 50,00 51,00 50 249,8 200,0 1,87
5578734
TCF505R4SL50MG 50,50 51,50 50 252,0 202,0 1,94
5578735
TCF510R4SL50MG 51,00 52,00 50 254,1 204,0 2,02
5578736
TCF520R4SL50MG 52,00 53,00 50 258,4 208,0 2,22
5578737
TCF530R4SL50MG 53,00 54,00 50 262,8 212,0 2,46
5578738
TCF540R4SL50MG 54,00 55,00 50 267,1 216,0 2,53
5578739
TCF550R4SL50MG 55,00 56,00 50 271,4 220,0 2,73
5578750
TCF560R4SL50MG 56,00 57,00 50 275,7 224,0 2,37
5538647
TCF570R4SL50MH 57,00 58,00 50 279,5 228,0 1,76
5538648
TCF580R4SL50MH 58,00 59,00 50 283,9 232,0 1,85
5538649
TCF590R4SL50MH 59,00 60,00 50 288,2 236,0 1,96
5538650
TCF600R4SL50MH 60,00 61,00 50 292,5 240,0 1,42
5538651
TCF610R4SL50MH 61,00 62,00 50 296,8 244,0 2,23
5538652
TCF620R4SL50MH 62,00 63,00 50 301,1 248,0 2,41
5538653
TCF630R4SL50MH 63,00 64,00 50 305,5 252,0 2,64
5538654
TCF640R4SL50MH 64,00 65,00 50 309,8 256,0 2,94
5538655
TCF650R4SL50MH 65,00 66,00 50 314,1 260,0 3,06
5538656
TCF660R4SL50MH 66,00 67,00 50 318,4 264,0 3,18
5538657
TCF670R4SL50MH 67,00 68,00 50 322,7 268,0 3,30
5538658
TCF680R4SL50MH 68,00 69,00 50 327,1 272,0 2,93
insert
size
E
E
E
E
E
F
F
F
F
F
F
F
F
F
F
G
G
G
G
G
G
G
G
G
G
G
G
H
H
H
H
H
H
H
H
H
H
H
H
periphery
insert
TCF100408EP
TCF100408EP
TCF100408EP
TCF100408EP
TCF100408EP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF120412FP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF150512GP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
TCF180614HP
centre
insert
TCF120405EC
TCF120405EC
TCF120405EC
TCF120405EC
TCF120405EC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF150406FC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF180508GC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
TCF210608HC
(continued)
