Indexable Drills
Top Cut 4™ Shanks
For information on LS, see the table on page V19.
Top Cut 4 Drill • Metric • 5 x D • SL Shanks
order number
catalogue number
D1
D
L1
L4 max
L5
5537874
TCF120R5SL20MA
12,00 20
86,0
60,0 0,41
5537875
TCF125R5SL20MA
12,50 20
89,0
63,0 0,48
5537876
TCF127R5SL20MA
12,70 20
90,0
63,5 0,51
5537877
TCF130R5SL20MA
13,00 20
90,0
65,0 0,56
5537878
TCF135R5SL20MA
13,50
20
94,0
68,0 0,64
5577948
TCF140R5SL25MB
14,00
25
99,0
70,0 0,42
5577949
TCF145R5SL25MB 14,50 25 100,0 72,5 0,45
5577950
TCF150R5SL25MB 15,00 25 103,0 75,0 0,49
5577951
TCF155R5SL25MB 15,50 25 104,8 77,5 0,54
5577952
TCF160R5SL25MB 16,00 25 108,4 80,0 0,60
5577953
TCF165R5SL25MB 16,50 25 111,1 82,5 0,68
5577954
TCF170R5SL25MB 17,00 25 115,4 85,0 0,74
5577955
TCF175R5SL25MB 17,50 25 118,1 87,5 0,79
5577956
TCF180R5SL25MB 18,00 25 120,8 90,0 0,86
5577957
TCF185R5SL25MB 18,50 25 122,4 92,5 0,83
5578844
TCF190R5SL25MC 19,00 25 129,1 95,0 0,60
5578845
TCF195R5SL25MC 19,50 25 131,7 97,5 0,70
5578846
TCF200R5SL25MC 20,00 25 132,0
100,0
0,70
5578847
TCF205R5SL25MC 20,50 25 134,1
102,5
0,70
5578848
TCF210R5SL25MC 21,00 25 137,0
105,0
0,80
5578849
TCF220R5SL25MC 22,00 25 142,0
110,0
1,00
5578850
TCF225R5SL25MC 22,50 25 144,7
112,5
1,10
5578851
TCF230R5SL25MC 23,00 25 147,0
115,0
1,10
5537838
TCF240R5SL25MD 24,00 25 152,0
120,0
0,78
5537839
TCF250R5SL32MD 25,00 32 158,0
125,0
0,86
5537840
TCF260R5SL32MD 26,00 32 164,0
130,0
0,97
5537841
TCF265R5SL32MD 26,50 32 166,5
132,5
1,05
5537842
TCF270R5SL32MD 27,00 32 170,0
135,0
1,15
5537843
TCF280R5SL32MD 28,00 32 176,5
140,0
1,30
5537844
TCF290R5SL32MD 29,00 32 181,0
145,0
1,45
5537958
TCF300R5SL32ME 30,00 32 186,0
150,0
0,63
5537959
TCF310R5SL32ME 31,00 32 193,0
155,0
0,72
insert
size
A
A
A
A
A
B
B
B
B
B
B
B
B
B
B
C
C
C
C
C
C
C
C
D
D
D
D
D
D
D
E
E
periphery
insert
TCF040204AP
TCF040204AP
TCF040204AP
TCF040204AP
TCF040204AP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF050204BP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF070306CP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF080308DP
TCF100408EP
TCF100408EP
centre
insert
TCF040203AC
TCF040203AC
TCF040203AC
TCF040203AC
TCF040203AC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF060203BC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF070304CC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF090305DC
TCF120405EC
TCF120405EC
(continued)
