Indexable Drills
Top Cut 4™ Shanks
для размещения заказа - zakaz@widiahanita.ru
(Top Cut 4 Drill • Metric • 4 x D • SL Shanks — continued)
Spare Parts
insert
size
periphery
insert
centre
insert screw
Torx
Torx driver
tightening
insert
order number
size
order number
torque Nm
A
TCF040204AP
TCF040203AC
2025073
T5
2029221
0,40
B
TCF050204BP
TCF060203BC
1175225
T6
1138455
0,53
C
TCF070306CP
TCF070304CC
1021337
T7
2029266
0,90
D
TCF080308DP
TCF090305DC
1134385
T8
2029598
1,10
E
TCF100408EP
TCF120405EC
2018194
T9
1138430
2,00
F
TCF120412FP
TCF150406FC
1756815
T15
2029596
4,00
G
TCF150512GP
TCF180508GC
1099645
T20
2029488
6,30
H
TCF180614HP
TCF210608HC
1823871
T25
1022519
8,80
D
20,00
25,00
32,00
40,00
50,00
LS
50
56
60
70
80
NOTE: Drilling in stacked plates possible in certain applications. Ask for technical support.
Drill shipped with insert screws and Torx wrench.
See pages V20–V23 for inserts.
SL = Side Lock
D1 max is an achievable diameter using x-offset.
WARNING
During through-hole operations, a slug or disc is produced
as the tool breaks through the workpiece. When the drill
is stationary and the workpiece is rotating, this slug may be
hurled from the chuck by centrifugal force. Provide adequate
shielding to protect bystanders.
