Multipurpose Taps
VariTap™ Spiral-Point HSS-E Taps • Through Holes
3–5
Shank Tolerance
D mm
tolerance h9
1–3 +0, -0,025
>3–6
+0, -0,030
>6–10
+0, -0,036
>10–18
+0, -0,043
>18–30
+0, -0,052
VT-SPO • Form B Plug Chamfer • Machine Screw and Fractional • DIN 371 and 376
first choice
alternate choice
graWdeUW41UE4G1EG
TiN
order # catalogue #
5472633 VTSPO6005
5472635 VTSPO6007
5472636 VTSPO6008
5472638 VTSPO6010
5472639 VTSPO6011
5472641 VTSPO6013
5472644 VTSPO6014
5472646 VTSPO6016
5472647 VTSPO6017
5472649 VTSPO6019
5472650 VTSPO6020
5472652 VTSPO6022
5472653 VTSPO6023
5472655 VTSPO6025
5472656 VTSPO6026
5472658 VTSPO6028
5472659 VTSPO6029
5472661 VTSPO6031
5472662 VTSPO6032
5472663 VTSPO6033
gradWePW49PE4G9EG
Oxide
order # catalogue #
5387704 VTSPO6005
5387707 VTSPO6007
5387708 VTSPO6008
5387760 VTSPO6010
5387761 VTSPO6011
5387763 VTSPO6013
5387764 VTSPO6014
5387766 VTSPO6016
5387767 VTSPO6017
5387769 VTSPO6019
5387770 VTSPO6020
5387772 VTSPO6022
5387773 VTSPO6023
5387776 VTSPO6025
5387777 VTSPO6026
5387779 VTSPO6028
5387780 VTSPO6029
5387782 VTSPO6031
5387783 VTSPO6032
5387784 VTSPO6033
D1 size
4 - 40
5 - 40
6 - 32
6 - 40
8 - 32
10 - 24
10 - 32
1/4 - 20
1/4 - 28
5/16 - 18
5/16 - 24
3/8 - 16
3/8 - 24
7/16 - 14
7/16 - 20
1/2 - 13
1/2 - 20
9/16 - 12
9/16 - 18
5/8 - 11
metric dimensions
L L3 L2 D
56 8 18 3,5
56 9 20 4,0
56 9 20 4,0
56 9 20 4,0
63 11 21 4,5
70 12 25 6,0
70 12 25 6,0
80 15 30 7,0
80 15 30 7,0
90 15 35 8,0
90 15 35 8,0
100 19 39 10,0
100 19 39 10,0
100 18 41
8,0
100 18 41
8,0
110 23 47
9,0
110 23 47
9,0
110 25 53 11,0
110 25 53 11,0
110 24 51 12,0
number
of utes
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
3
3
3
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 376
DIN 376
DIN 376
DIN 376
DIN 376
DIN 376
DIN 376
class
of t
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
(continued)
