High-Performance Taps

Victory™ Spiral-Point Plug HSS-E-PM Taps • Through Holes

• WP31MG TiN for steel

32–44 HRC.

GT00 • Form B Plug Chamfer • Metric DIN 371, 374, and 376 • For Hard Steel

Shank Tolerance

D mm

tolerance h9

1–3 +0, -0,025

>3–6 +0, -0,030

>6–10

+0, -0,036

>10–18

+0, -0,043

>18–30

+0, -0,052

first choice

alternate choice

gradWePW31PM31GMG

TiN

order # catalogue #

4153679 GT005001

4153680 GT005002

4153681 GT005003

4153682 GT005004

4153760 GT005012

4153753 GT005005

4153761 GT005013

4153762 GT005014

4153754 GT005006

4153763 GT005015

4153764 GT005016

4153755 GT005007

4153765 GT005017

4153756 GT005008

4153766 GT005018

4153757 GT005009

4153758 GT005010

4153759 GT005011

D1 size

M3 X 0,5

M4 X 0,7

M5 X 0,8

M6 X 1

M8 X 1

M8 X 1,25

M10 X 1

M10 X 1,25

M10 X 1,5

M12 X 1,25

M12 X 1,5

M12 X 1,75

M14 X 1,5

M14 X 2

M16 X 1,5

M16 X 2

M18 X 2

M20 X 2,5

metric dimensions

L L3 L2 D

56 11 18 3,5

63 13 21 4,5

70 15 25 6,0

80 17 30 6,0

90 17 — 6,0

90 20 35 8,0

90 18 — 7,0

100 22 —

7,0

100 22 39 10,0

100 22 —

9,0

100 22 —

9,0

110 24 —

9,0

100 22 — 11,0

110 26 — 11,0

100 22 — 12,0

110 27 — 12,0

125 30 — 14,0

140 32 — 16,0

number

of utes

dimension

standard

DIN 371

DIN 374

DIN 371

DIN 374

DIN 371

DIN 374

DIN 376

DIN 374

DIN 376

DIN 374

DIN 376

class

of t

6HX

Y10
