Multipurpose Taps
VariTap™ Spiral-Point HSS-E Taps • Through Holes
(VT-SPO • Form B Plug Chamfer • Metric DIN 371, 374, and 376 — continued)
first choice
alternate choice
graWdePW42PE4G2EG
TiCN
graWdeUW41UE4G1EG
TiN
graWdePW49PE4G9EG
Oxide
gradWeUW40UE4G0EG
Bright
order # catalogue # order # catalogue # order # catalogue # order # catalogue # D1 size
metric
dimensions
L L3 L2 D
number dimension class
of utes standard of t
5366693 VTSPO6519 5366692 VTSPO6519 5366695 VTSPO6519 5366696 VTSPO6519 M7 X 1 80 12 30 7,0 3 DIN 371 6H
–
– 5366697 VTSPO6520 –
M7 X 1 80 12 30 7,0 3 DIN 371 6G
– – 5368614 VTSPO6551 5368615 VTSPO6551 M8 X 0,75 80 12 30 6,0 3 DIN 374 6H
– – 5368616 VTSPO6552 5368617 VTSPO6552 M8 X 1 90 15 35 6,0 3 DIN 374 6H
– 5368546 VTSPO6529 5368547 VTSPO6529 5368548 VTSPO6529 M8 X 1,25 90 15 35 6,0 3 DIN 376 6H
5366700 VTSPO6521 5366698 VTSPO6521 5366701 VTSPO6521 5366703 VTSPO6521 M8 X 1,25 90 15 35 8,0 3 DIN 371 6H
–
– 5366704 VTSPO6522 –
M8 X 1,25 90 15 35 8,0 3 DIN 371 6G
– – 5368618 VTSPO6553 5368619 VTSPO6553 M10 X 0,75 90 15 35 7,0 3 DIN 374 6H
– – 5368620 VTSPO6554 5368621 VTSPO6554 M10 X 1 90 15 35 7,0 3 DIN 374 6H
– – 5368622 VTSPO6555 5368623 VTSPO6555 M10 X 1,25 100 18 39 7,0 3 DIN 374 6H
–
– 5366709 VTSPO6524 –
M10 X 1,5 100 18 39 10,0 3 DIN 371 6G
5366706 VTSPO6523 5366705 VTSPO6523 5366707 VTSPO6523 5366708 VTSPO6523 M10 X 1,5 100 18 39 10,0 3 DIN 371 6H
– 5368549 VTSPO6530 5368550 VTSPO6530 5368551 VTSPO6530 M10 X 1,5 100 18 39 7,0 3 DIN 376 6H
– – 5368624 VTSPO6556 5368625 VTSPO6556 M11 X 1 90 15 36 8,0 3 DIN 374 6H
– – 5368626 VTSPO6557 5368627 VTSPO6557 M12 X 1 100 21 39 9,0 3 DIN 374 6H
– – 5368628 VTSPO6558 5368629 VTSPO6558 M12 X 1,25 100 21 39 9,0 3 DIN 374 6H
– – 5368630 VTSPO6559 5368631 VTSPO6559 M12 X 1,5 100 21 39 9,0 3 DIN 374 6H
– – 5368556 VTSPO6532 – M12 X 1,75 110 21 44 9,0 3 DIN 376 6G
5368553 VTSPO6531 5368552 VTSPO6531 5368554 VTSPO6531 5368555 VTSPO6531 M12 X 1,75 110 21 44 9,0 3 DIN 376 6H
– – 5368632 VTSPO6560 5368633 VTSPO6560 M14 X 1 100 21 47 11,0 3 DIN 374 6H
– – 5368634 VTSPO6561 5368635 VTSPO6561 M14 X 1,25 100 21 47 11,0 3 DIN 374 6H
– – 5368636 VTSPO6562 5368637 VTSPO6562 M14 X 1,5 100 21 47 11,0 3 DIN 374 6H
5368558 VTSPO6533 5368557 VTSPO6533 5368559 VTSPO6533 5368560 VTSPO6533 M14 X 2 110 24 52 11,0 3 DIN 376 6H
–
– 5368561 VTSPO6534 –
M14 X 2 110 24 52 11,0 3 DIN 376 6G
– – 5368638 VTSPO6563 5368639 VTSPO6563 M16 X 1 100 21 46 12,0 3 DIN 374 6H
– – 5368640 VTSPO6564 5368641 VTSPO6564 M16 X 1,5 100 21 46 12,0 3 DIN 374 6H
5368563 VTSPO6535 5368562 VTSPO6535 5368565 VTSPO6535 5368566 VTSPO6535 M16 X 2 110 24 51 12,0 3 DIN 376 6H
–
– 5368567 VTSPO6536 –
M16 X 2 110 24 51 12,0 3 DIN 376 6G
– – 5368642 VTSPO6565 5368643 VTSPO6565 M18 X 1 110 21 50 14,0 3 DIN 374 6H
– – 5368683 VTSPO6566 5368684 VTSPO6566 M18 X 1,5 110 21 50 14,0 3 DIN 374 6H
– – 5368685 VTSPO6567 5368686 VTSPO6567 M18 X 2 125 30 58 14,0 3 DIN 374 6H
5368569 VTSPO6537 5368568 VTSPO6537 5368570 VTSPO6537 5368571 VTSPO6537 M18 X 2,5 125 30 58 14,0 3 DIN 376 6H
– – 5368687 VTSPO6568 5368688 VTSPO6568 M20 X 1 125 24 56 16,0 3 DIN 374 6H
– – 5368689 VTSPO6569 5368690 VTSPO6569 M20 X 1,5 125 24 56 16,0 3 DIN 374 6H
– – 5368691 VTSPO6570 5368692 VTSPO6570 M20 X 2 140 30 64 16,0 3 DIN 374 6H
5368573 VTSPO6538 5368572 VTSPO6538 5368574 VTSPO6538 5368575 VTSPO6538 M20 X 2,5 140 30 64 16,0 3 DIN 376 6H
(continued)
