High-Performance Taps

Victory™ Spiral-Flute HSS-E-PM Taps • Threading Close to the Bottom in a Blind Hole

• GP6520 TiCN for steel.

Shank Tolerance

D mm

tolerance h6

>3–6 +0, -0,008

>6–10

+0, -0,009

>10–18

+0, -0,011

>18–30

+0, -0,013

>30–50

+0, -0,016

GT32 • Form E Bottoming Chamfer • Metric DIN 371, 374, and 376 • For Steel

first choice

alternate choice

graGdeP6G5P260520

TiCN

order # catalogue #

4153906 GT325001

4153907 GT325002

4153908 GT325003

4153909 GT325004

4153912 GT325007

4153910 GT325005

4153953 GT325008

4153911 GT325006

4153954 GT325009

D1 size

M5 X 0,8

M6 X 1

M8 X 1,25

M10 X 1,5

M12 X 1,5

M12 X 1,75

M14 X 1,5

M14 X 2

M16 X 1,5

metric dimensions

L L3 L2

70 10 25

80 10 30

90 13 35

100 15 39

100 15 39

110 18 44

100 15 47

110 20 52

100 15 46

D

6,0

6,0

8,0

10,0

9,0

9,0

11,0

11,0

12,0

number

of utes

3

3

3

3

4

4

4

4

4

dimension

standard

DIN 371

DIN 371

DIN 371

DIN 371

DIN 374

DIN 376

DIN 374

DIN 376

DIN 374

class

of t

6HX

6HX/div>
