WIDIA - Полный каталог инструмента - 2017
• GP6520 TiCN for steel.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Spiral-Flute HSS-E-PM Taps • Threading Close to the Bottom in a Blind Hole
Shank Tolerance
D mm
tolerance h6
>3–6
+0, -0,008
>6–10
+0, -0,009
>10–18
+0, -0,011
>18–30
+0, -0,013
>30–50
+0, -0,016
GT33 • Form E Bottoming Chamfer • Through Coolant • Metric DIN 371, 374, and 376 • For Steel
first choice
alternate choice
graGdeP6G5P260520
TiCN
order # catalogue #
4153955 GT335001
4153956 GT335002
4153957 GT335003
4153958 GT335004
4153961 GT335007
4153959 GT335005
4153962 GT335008
4153960 GT335006
4153963 GT335009
D1 size
M5 X 0,8
M6 X 1
M8 X 1,25
M10 X 1,5
M12 X 1,5
M12 X 1,75
M14 X 1,5
M14 X 2
M16 X 1,5
metric dimensions
L L3 L2
70 10 25
80 10 30
90 13 35
100 15 39
100 15 39
110 18 44
100 15 47
110 20 52
100 15 46
D
6,0
6,0
8,0
10,0
9,0
9,0
11,0
11,0
12,0
number
of utes
3
3
3
3
4
4
4
4
4
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 374
DIN 376
DIN 374
DIN 376
DIN 374
class
of t
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
zakaz@widiahanita.ru
www.widiahanita.ru
Y25
