• WN35MG TiN/DLC for titanium
and titanium alloys.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Spiral-Flute HSS-E-PM Taps • Blind Holes
Shank Tolerance
D mm
tolerance h9
1–3 +0, -0,025
>3–6
+0, -0,030
>6–10
+0, -0,036
>10–18
+0, -0,043
>18–30
+0, -0,052
GT16 • Form C Semi-Bottoming Chamfer • Metric DIN 371 • For Titanium and Titanium Alloys
first choice
alternate choice
grWadNe3W5MNG35MG
TiN/DLC
order # catalogue #
4160437 GT165001
4160438 GT165002
4160439 GT165003
4160440 GT165004
4160441 GT165005
4160442 GT165006
4160523 GT165007
D1 size
M3 X 0,5
M4 X 0,7
M5 X 0,8
M6 X 1
M8 X 1,25
M10 X 1,5
M12 X 1,75
metric dimensions
L L3 L2 D
56 6 18 3,5
63 7 21 4,5
70 8 25 6,0
80 10 30 6,0
90 14 35 8,0
100 16 39 10,0
110 18 44 12,0
number
of utes
3
3
3
3
3
3
3
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
class
of t
6HX
6HX
6HX
6HX
6HX
6HX
6HX
