High-Performance Taps
Victory™ Spiral-Flute HSS-E Taps • Blind Holes
• WN48EG DLC for aluminium.
Shank Tolerance
D mm
tolerance h9
1–3 +0, -0,025
3,5–6
+0, -0,030
7–10 +0, -0,036
11–18
+0, -0,043
GT80 • Form C Semi-Bottoming Chamfer • Metric DIN 371 and 376 • For Aluminium
first choice
alternate choice
graWdeNW48NE4G8EG
DLC
order # catalogue #
4160054 GT805001
4160055 GT805002
4160056 GT805003
4160057 GT805004
4160058 GT805005
4160059 GT805006
4160060 GT805007
4160061 GT805008
4160062 GT805009
D1 size
M3 X 0,5
M4 X 0,7
M5 X 0,8
M6 X 1
M8 X 1,25
M10 X 1,5
M12 X 1,75
M16 X 2
M20 X 2,5
metric dimensions
L L3 L2
56 6 18
63 7 21
70 8 25
80 10 30
90 14 35
100 16 39
110 18 —
110 22 —
140 25 —
D
3,5
4,5
6,0
6,0
8,0
10,0
9,0
12,0
16,0
number
of utes
2
2
2
2
2
2
3
3
3
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 376
DIN 376
DIN 376
class
of t
6H
6H
6H
6H
6H
6H
6H
6H
6H
Y32
