• WN14PG TiN + CrC/C
for aluminium.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Solid Carbide Straight-Flute Taps • Blind Holes
Shank Tolerance
D tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–16
+0, -0,011
GX47 • Form E Bottoming Chamfer • Through Coolant • Metric • For Aluminium
graWdeNW14NP1G4PG
TiN+CrC/C
order # catalogue #
5520839 GX475006
5520840 GX475008
5520841 GX475010
D1 size
M6 X 1
M8 X 1,25
M10 X 1,5
first choice
alternate choice
metric dimensions
L L3 L2 D
80 10 30 6,0
90 10 35 8,0
100 15 39 10,0
number
of utes
3
3
3
class
of t
6HX
6HX
6HX
