High-Performance Taps
Victory™ Solid Carbide Straight-Flute Taps • Blind Holes
• WN14PG TiN + CrC/C
for aluminium.
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–16
+0, -0,011
GX47 • Form E Bottoming Chamfer • Through Coolant • Metric • For Aluminium
first choice
alternate choice
graWdeNW14NP1G4PG
TiN+CrC/C
order # catalogue #
5551161 GX472866
5551162 GX472867
5551163 GX472868
5551164 GX472872
5551165 GX472870
5551166 GX472874
5551167 GX472873
5551168 GX472875
metric dimensions
D1 size
L L3 L2 LS D
M6 X 1
70 12 24 42 6,0
M8 X 1,25 80 15 32 43 8,0
M10 X 1,5 90 18 40 44 10,0
M12 X 1,5 100 21 48 46 12,0
M12 X 1,75 100 21 48 46 12,0
M14 X 1,5 110 24 56 52 12,0
M14 X 2
110 24 56 52 12,0
M16 X 2
110 24 64 44 14,0
number
of utes
3
3
3
3
3
4
4
4
class
of t
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
Y50
