High-Performance Taps
Victory™ Solid Carbide Forming Taps • Blind Holes
• WN14PG TiN + CrC/C
for aluminium.
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–16
+0, -0,011
GX49 • Form E Bottoming Entry Taper • Through Coolant • Metric • For Aluminium
gradWeNW14NP1G4PG
TiN+CrC/C
order # catalogue #
5520842 GX495006
5520843 GX495008
5520844 GX495010
D1 size
M6 X 1
M8 X 1,25
M10 X 1,5
metric dimensions
L L3 L2 D
80 10 30 6,0
90 13 35 8,0
100 15 39 10,0
first choice
alternate choice
number of
lube grooves
2
2
3
class
of t
6HX
6HX
6HX
Y60
