• WN14PG TiN + CrC/C
for aluminium.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Solid Carbide Forming Taps • Blind Holes
Shank Tolerance
D tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–16
+0, -0,011
GX49 • Form E Bottoming Entry Taper • Through Coolant • Metric • For Aluminium
first choice
alternate choice
gradWeNW14NP1G4PG
TiN+CrC/C
order # catalogue #
D1 size
metric dimensions
number of
class
L
L3 L2 LS
D
lube grooves
of t
5551169 GX492908
M6 X 1
70 8 24 42 6,0
2
6HX
5551170 GX492909
M8 X 1,25
80 10 32 43 8,0
2
6HX
5551171 GX492911
M10 X 1,5
div class="txt" style="position:absolute; left:246px; top:443px;">90 12 40 44 10,0
3
6HX
5551173 GX492915
M12 X 1,5 100 14 48 46 12,0
3
6HX
5551172 GX492914
M12 X 1,75 100 14 48 46 12,0
3
6HX
