• WP31MG TiN for steel.

• WN38MG DLC for aluminium.

для размещения заказа - zakaz@widiahanita.ru

High-Performance Taps

Victory™ Forming Taps HSS-E-PM • Blind and Through Holes

Shank Tolerance

D mm

tolerance h9

1–3 +0, -0,025

>3–6

+0, -0,030

>6–10

+0, -0,036

>10–18

+0, -0,043

>18–30

+0, -0,052

GT23 • Form C Semi-Bottoming Entry Taper • Through Coolant • Metric DIN 2174 • For Steel

and Aluminium

first choice

alternate choice

gradWePW31PM31GMG

TiN

order # catalogue #

4159965 GT235012

4159966 GT235013

4159971 GT235018

4159967 GT235014

4159972 GT235019

4159968 GT235015

4159993 GT235020

4159969 GT235016

4159994 GT235021

4159995 GT235022

4159970 GT235017

gradWeNW38NM38GMG

DLC

order # catalogue #

4159522 GT235001

4159644 GT235002

4159649 GT235007

4159645 GT235003

4159650 GT235008

4159646 GT235004

4159651 GT235009

4159647 GT235005

4159652 GT235010

4159653 GT235011

4159648 GT235006

D1 size

M5 X 0,8

M6 X 1

M8 X 1

M8 X 1,25

M10 X 1

M10 X 1,5

M12 X 1,5

M12 X 1,75

M14 X 1,5

M16 X 1,5

M16 X 2

metric dimensions

L L3 L2 D

70 8 25 6,0

80 10 30 6,0

90 10 35 8,0

90 14 35 8,0

90 10 35 10,0

100 16 39 10,0

100 15 —

9,0

110 18 —

9,0

100 15 — 11,0

100 15 — 12,0

110 22 — 12,0

dimension

standard

DIN 2174

class

of t

6HX
