Standard Pipe Tap Dimensions • Straight and Taper • Ground Thread • Reference USCTI Table 311
General Dimensions
dimensions (in)
nominal
size
(in)
1/16
1/8
1/8
1/4
3/8
1/2
3/4
1
1-1/4
1-1/2
2
2-1/2
3
3-1/2
4
overall
length
L
2.13
2.13
2.13
2.44
2.56
3.13
3.25
3.75
4.00
4.25
4.25
5.50
6.00
6.50
6.75
thread
length
l
.69
.75
.75
1.06
1.06
1.38
1.38
1.75
1.75
1.75
1.75
2.56
2.63
2.69
2.75
square
length
l2
.38
.38
.38
.44
.50
.63
.69
.81
.94
1.00
1.13
1.25
1.38
1.50
1.56
shank
diameter
D1
.3125
.3125
.4375
.5625
.7000
.6875
.9063
1.1250
1.3125
1.5000
1.8750
2.2500
2.6250
2.8125
3.0000
square
size
A
.234
.234
.328
.421
.531
.515
.679
.843
.984
1.125
1.406
1.687
1.968
2.108
2.250
optional
neck
length
l1
.375
–
.375
.375
.375
–
–
–
–
–
–
–
–
–
–
