Tapping Icons
Tapping:
Blind Hole
Threading:
Through Hole
Threading:
Blind Hole
HM: (Carbide)
Square Shank
3–5
Plug Chamfer (3–5)
Tapping Helix:
Angle: L15°
Tapping Helix:
Angle: 0°
Tapping Helix:
Angle: 25°
DIN Number 371
DIN Number 374
Flood Coolant:
Tapping
Through Coolant:
Axial: Tapping
Class of Fit: 3B
Class of Fit: 6H
Unified Course
Thread: J Profile
Unified Fine Thread:
J Profile
ISO Metric
Fine Thread
DIN — German Institute for Standardisation
Chamfer Form C
(2–3)
Tapping Helix:
Angle: 10°
Tapping Helix:
Angle: 30°
DIN Number 2174
ISO 2
Class of Fit: 6HX
Unified Fine
Thread
HSS-E: High-Speed
Steel with Cobalt Alloy
for Materials with
Higher Hardness
Chamfer Form D
(3.5–5)
Tapping Helix:
Angle: L8°
Tapping Helix:
Angle: 42°
DIN Number 376
Manufacturer’s
Specs: JIS
Class of Fit: 6G
Unified Course
Thread
HSS-E-PM:
High-Speed Steel
with Cobalt Alloy for
Materials with Higher
Hardness (PM = Power
Metal Steel)
Chamfer Form E
(1.5–2)
Tapping Helix:
Angle: 15°
Tapping Helix:
Angle: 45°
Tapping: Through
Coolant
Class of Fit: 2B
ANSI
ISO Metric
Coarse Thread
Z150
