Toolholder Selection Guide
для размещения заказа - zakaz@widiahanita.ru
Each unique clamping system offers product options to fill your
specific toolholder needs. Find the illustration that fits your application
and navigate to the corresponding page to get the correct solution.
D-Style Clamping
D
One-piece clamp
assembly holder for
use with negative style
inserts. An extremely
rigid clamping system.
The tool is protected
by a carbide shim.
P-Style Clamping
P
Lever-type clamping
system for negative
indexable inserts with
hole to DIN 4988 and
positive round inserts
more than 20mm in
diameter. Inserts with
one- and two-side chip
control geometries have
positive rakes from 6°
to 18°. Advantages of
this system are fast
insert changes and
no interference with
chip flow.
DCKN
75°
Page:
C8
DDJN
93°
Page:
C11
DSKN
75°
Page:
C13
DTGN
90°
Page:
C16
DWLN
95°
Page:
C19
PCBN
75°
Page:
C20
PDNN
62,5°
Page:
C24
PSSN
45°
Page:
C27
DCKN
Page: C8
Product Name
Application Illustration
Page Number
DCLN
95°
Page:
C9
DDNN
63°
Page:
C11
DSRN
75°
Page:
C14
DVJN
93°
Page:
C17
DCRN
75°
Page:
C10
DRGN
Page:
C12
DSSN
45°
Page:
C15
DVON
117,5°
Page:
C18
DCSN
45°
Page:
C10
DSDN
45°
Page:
C12
DTFN
90°
Page:
C16
DVVN
72,5°
Page:
C18
PCKN
75°
Page:
C21
PSBN
75°
Page:
C25
PTFN
90°
Page:
C28
PCLN
95°
Page:
C22
PSDN
45°
Page:
C26
PTGN
90°
Page:
C29
PDJN
93°
Page:
C23
PSKN
75°
Page:
C26
PWLN
95°
Page:
C30
